Specifications

Bonus Area:	475 sq ft
Garage Area:	816 sq ft
Garage Type:	Detached
Garage Bays:	2
Foundation Types:	Slab
Exterior Walls:	2x4
House Width:	36'
House Depth:	24'
Number of Stories:	2
Max Ridge Height:	23'10 from Front Door Floor Level
Primary Roof Pitch:	12:12
Roof Load:	47 psf
Roof Framing:	Truss
Main Ceiling Height:	9'
Upper Ceiling Height:	9'

Plan Description

Shingled siding, shutters and carriage doors highlight this craftsman-inspired detached garage plan. A finished loft with tapered ceilings is found on the second level while two stalls and plenty of extra storage completes the main level.

What's Included?

Cover sheet with Front Rendering.

Foundation and Floor Plans at 1/4" = 1'0" scale.

Exterior Elevations of all four views, front at 1/4" = 1'0" scale, rear and sides vary from 1/8" to 1/4" = 1'0" scale.

Building Sections and Details as required to construct the individual design.

Interior Elevations of Cabinets at 1/4" = 1'0" scale.

Roof Plans

Schematic Electrical Plans with suggested switch, outlet, and light fixture locations.

General Specifications design notes.

Note: Mechanical and Plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
