Specifications

Total Living Area:	1727 sq ft
Main Living Area:	1437 sq ft
Upper Living Area:	290 sq ft
Garage Area:	608 sq ft
Garage Type:	Attached
Garage Bays:	2
Foundation Types:	Crawlspace
Exterior Walls:	2x4
House Width:	52'
House Depth:	43'0
Number of Stories:	2
Bedrooms:	2
Full Baths:	2
Max Ridge Height:	29'6 from Front Door Floor Level
Primary Roof Pitch:	0
Roof Framing:	Stick
Porch:	597 sq ft
FirePlace:	Yes
1st Floor Master:	Yes
Main Ceiling Height:	9'

Special Features:

Front Porch
Outdoor Fireplace
Pantry
Storage Space

Plan Description

Rustic Vacation Style Lake House Plan with 1727 Sq Ft, 2 Beds, 2 Baths and a 2 Car Garage

Lakeside House Plan 86202 has 1,727 square feet of living space and 2 bedrooms. In addition, there is a sleeping loft upstairs. Choose this design for new construction on your lake property!

Lakeside House Plan exterior tour

This rustic cabin style design makes a great vacation home because there is room for everyone. Sitting riverside or on the lake, this floor plan with its deep front porch and fireplace, is where memories are made.

Firstly, the wraparound porch on Lakeside House Plan 86202 is big enough to host large cookouts. When you are vacationing by the lake, the goal should be to spend time outdoors. The lovely shaded porch measures 52' wide by 13'4 deep. You can fit a big table and lots of chairs. Grill steak and hamburgers to your heart's content and catch up with family.

Interior tour with room for everyone in the family

Secondly, all of your cousins and their kids will have a place to sleep. The master bedroom is on the main floor, and it has a private bathroom with double vanity. Plus, it has a walk-in closet and a linen closet. Bedroom 2 is on the main floor as well. It has an attached bathroom with double vanity. Guests will access this bathroom from the second doorway off the kitchen. Check out the loft upstairs. It has room for three twin beds for the kids.

Thirdly, the layout in Lakeside House Plan 86202 is open living space. When a big family is vacationing, you have lots of options to spread out. Uncle Joe and Aunt Mary will settle on the couch, and Mom and Dad will each select their favorite chair in the great room. Grandma and Grandpa will sit down across from them to reminisce.

The younger set of cousins will perch at the counter bar in the kitchen, and the older set will play a game of cards at the dining table. The family cook will whip up some snacks in the L-shaped kitchen.

What's Included?
