|Total Living Area:||1292 sq ft|
|Main Living Area:||1292 sq ft|
|Number of Stories:||2|
|Max Ridge Height:||32' from Front Door Floor Level|
|Primary Roof Pitch:||4:12|
We are sorry, but an estimated cost build is not available for this particular plan.
A: Exterior shop area walls are 2X6 stud construction, headed shop area walls are ICF construction.
A: 4 garage doors in the outer shop area: 10' X 9' Front heated shop on exterior wall: 18' X 12' Rear door from heated shop into outer shop area: 10' X 10'
A: Center garage door is called out as a 18' W X 12' H overhead garage door.
A: Hello, Heated work shop is 14' and loft is 8'-7 1/2".
A: The heated shop has 14' ceilings. Thank you!
A: 40 lbs live 10 lbs dead PSF ... can be adjusted up by using a larger bottom chord on the truss.
A: 8' at the low point... 8'-7" at the high point.
A: None, we used gambrel attic roof trusses which allowed us to remove any post in this area...
A: 12' high & 18' wide... Thank you,
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
