Garage Apartment Plan 45192 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 1135 Total Living Area
  • 71 Main Level
  • 1064 Upper Level
  • 2 Bedrooms
  • 2 Full Bath(s)
  • 3 Car Garage
  • 46'0 Wide x 28'0 Deep
Available Foundation Types:
  • Stem Wall Slab

Plan Pricing

  • PDF File: $730.00
  • CAD File: $850.00
  • Materials List: $90.00
  • Right Reading Reverse: $100.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
* prices shown w/o any discounts applied

Garage Plan 45192 | Order Code: 00WEB | Elevation

Reverse Plan


Garage Plan 45192 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage Plan 45192 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Garage Plan 45192 | Order Code: 00WEB | Rear Elevation

Specifications

  • Total Living Area: 1135
  • Main Living Area: 71
  • Upper Living Area: 1064
  • Garage Area: 993
  • Garage Type: Drive Under
  • Garage Bays: 3
  • House Width: 46'0
  • House Depth: 28'0
  • Number of Stories: 2
  • Bedrooms: 2
  • Full Baths: 2
  • Max Ridge Height: 26'8 from Front Door Floor Level
  • Primary Roof Pitch: 6:12
  • Roof Load: 40 psf
  • Roof Framing: Truss
  • FirePlace: Yes
  • Main Ceiling Height: 9'0
  • Upper Ceiling Height: 8'0

Available Foundation Types:

  • Stem Wall Slab

Plan Pricing

  • PDF File: $730.00
  • CAD File: $850.00
  • Materials List: $90.00
  • Right Reading Reverse: $100.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

The PDF file will also be included with the purchase of the CAD file.

* prices shown w/o any discounts applied

Special Features:

  • Deck or Patio
  • Open Floor Plan

Architectural Styles

Traditional

Garage Apartment House Plan with 1,135 Sq Ft, 2 Bed, 2 Bath, 3 Car Garage

Discover the versatility and comfort of this Traditional garage apartment house plan, offering 1,135 sq ft of thoughtfully designed living space above a generous 993 sq ft, 3-car drive-under garage. Perfect for multi-generational living, rental income, or a private guest suite, this plan seamlessly blends functionality with inviting style.

The exterior captures classic appeal with its balanced roofline and space-saving design. A dedicated outdoor staircase provides private access to the upper-level apartment, ensuring security and independence between the living quarters and garage below. A spacious deck or patio extends your living space outdoors, perfect for relaxing or entertaining guests.

Inside, the open floor plan creates an airy, connected environment ideal for both everyday living and hosting. The main sitting room features a cozy fireplace and built-in shelving, making it a welcoming spot to gather and unwind. The adjoining kitchen is efficiently laid out, providing all the amenities found in larger homes, from ample cabinetry to modern appliances—ensuring meal prep and dining are always a pleasure.

The primary suite offers a tranquil retreat, complete with a private full bathroom for added comfort and convenience. A second bedroom and additional full bath provide flexibility for family, guests, or a home office. Every inch of the apartment is optimized for livability, including a dedicated laundry closet designed to accommodate a stacked washer and dryer—making chores easy and convenient.

This plan's 3-car garage delivers ample space for vehicles, storage, or workshop needs. The stem wall slab foundation adds stability and ease of construction, while the traditional styling ensures the home blends beautifully with a variety of neighborhoods.

Whether you're seeking an income-producing rental, a secluded guest suite, or a comfortable in-law apartment, this garage apartment house plan offers the perfect balance of privacy, practicality, and style. Ideal for homeowners who value flexibility and efficient living, it's a smart investment in both lifestyle and future potential.
