Plan Number: 49164

  • 4 Car Garage
  • 24 Wide x 38 Deep
Available Foundation Types:
  • Stem Wall Slab

Order Code: 00WEB

  • 3 Sets: $225.00
  • 5 Sets: $260.00
  • 8 Sets: $325.00
  • PDF File: $300.00
  • CAD File: $425.00
  • Materials List: $40.00
  • Right Reading (True) Reverse: $50.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $25.00

Plan Number 49164 | Order Code: 00WEB | Elevation

Reverse Plan


Plan Number 49164 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Plan Number 49164 | Order Code: 00WEB | Rear Elevation

Plan Number 49164 Specifications:

  • Garage Area: 912
  • Garage Type: Detached
  • Garage Bays: 4
  • House Width: 24
  • House Depth: 38
  • Number of Stories: 1
  • Max Ridge Height: 14 from Front Door Floor Level
  • Primary Roof Pitch: 4:12
  • Roof Load: 40 psf
  • Roof Framing: Truss
  • Main Ceiling Height: 9
  • Upper Ceiling Height: 0
  • Vaulted Ceiling: Yes
  • Tray Ceiling: Yes

Available Foundation Types:

  • Stem Wall Slab

Plan Number 49164 Plan Pricing:

  • 3 Sets: $225.00
  • 5 Sets: $260.00
  • 8 Sets: $325.00
  • PDF File: $300.00
  • CAD File: $425.00
  • Materials List: $40.00

  • Right Reading (True) Reverse: $50.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

  • Additional Sets: $25.00
