Garage Apartment Plan 76029 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 913 Total Living Area
  • 106 Main Level
  • 807 Upper Level
  • 1 Bedrooms
  • 1 Full Bath(s)
  • 2 Half Bath(s)
  • 4 Car Garage
  • 54' Wide x 40' Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $745.00
  • Materials List: $70.00
  • Right Reading Reverse: $145.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
* prices shown w/o any discounts applied

Garage Plan 76029 | Order Code: 00WEB | Elevation

Reverse Plan


Garage Plan 76029 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage Plan 76029 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Garage Plan 76029 | Order Code: 00WEB | Rear Elevation

Specifications

  • Total Living Area: 913
  • Main Living Area: 106
  • Upper Living Area: 807
  • Garage Area: 1508
  • Garage Type: Drive Under
  • Garage Bays: 4
  • House Width: 54'
  • House Depth: 40'
  • Number of Stories: 2
  • Bedrooms: 1
  • Full Baths: 1
  • Half Baths: 2
  • Max Ridge Height: 25'3 from Front Door Floor Level
  • Primary Roof Pitch: 10:12
  • Roof Load: 34 psf
  • Roof Framing: Truss and/or Stick
  • Porch: 46 sq ft
  • Main Ceiling Height: 9' + 14'
  • Upper Ceiling Height: 8'

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $745.00
  • Materials List: $70.00
  • Right Reading Reverse: $145.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

RV Garage - 740 sq. ft.
Double Garage - 504 sq. ft.
Single Garage - 264 sq. ft.
Workshop - 216 sq. ft.

* prices shown w/o any discounts applied

The RV garage portion of this combination garage has a fourteen foot high ceiling accessed though a twelve foot high by twelve foot wide overhead door. The double car garage has a nine foot high ceiling with a sixteen foot wide by eight foot high overhead door. The single car garage has a nine foot high ceiling with an eight foot wide by seven foot high overhead door.

The covered porch double doors open into the ample workshop with a nine foot high ceiling and contains a conveniently located powder bathroom. The workshop provides double door access to both the RV and double car garage areas to facilitate easy equipment movement between units.

The single car garage is dedicated to the second level apartment which is accessed through the rear entry. The apartment office overlooks the lower vaulted ceiling entry and boasts a skylight. The remaining apartment area has an eight foot ceiling. The versatile open concept great room is natural lit with a front facing window wall.

Plans are designed with a concrete slab foundation plan.
