Specifications

  • 3 Car Garage
  • 40'0 Wide x 28'0 Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $960.00
  • 1 Set: $380.00
  • 5 Sets plus PDF File: $620.00
  • CAD File: $1,065.00
  • CAD File Unlimited Build: $1,170.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Right Reading Reverse: $75.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $25.00
* prices shown w/o any discounts applied

Garage Plan 78478 | Order Code: 00WEB | Elevation

Reverse Plan


Garage Plan 78478 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage Plan 78478 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Garage Plan 78478 | Order Code: 00WEB | Rear Elevation

Specifications

  • Bonus Area: 1517
  • Garage Area: 728
  • Garage Type: Detached
  • Garage Bays: 3
  • House Width: 40'0
  • House Depth: 28'0
  • Number of Stories: 2
  • Max Ridge Height: 24'9 from Front Door Floor Level
  • Primary Roof Pitch: 8:12
  • Roof Load: 35 psf
  • Roof Framing: Truss and/or Stick
  • Main Ceiling Height: 9'
  • Upper Ceiling Height: 8'

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $960.00
  • 1 Set: $380.00 **
  • 5 Sets plus PDF File: $620.00
  • CAD File: $1,065.00
  • CAD File Unlimited Build: $1,170.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Right Reading Reverse: $75.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $25.00

** 1 Set order does not include a License-To-Build. For bidding purposes only. Customer can upgrade order within 90 days.

* prices shown w/o any discounts applied

Architectural Styles

Country, Craftsman, Traditional

Traditional Garage Plan

Size and amenities are the name of the game with this Traditional style garage design. To the right is a covered carport meant for a single car that can also double as a storage area. The building has two stories with stairs on the inside placed conveniently out of the way on the back-right wall. The first floor is made up of the garage space that can house two cars, with the doors of each bay measuring 10' x 8'. The second floor is an open storage area with 8' ceilings.
