Plan 81840 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 4101 Total Living Area
  • 1658 Lower Level
  • 1658 Main Level
  • 785 Upper Level
  • 5 Bedrooms
  • 3 Full Bath(s)
  • 1 Half Bath(s)
  • 2 Car Garage
  • 60'4 Wide x 51'10 Deep
Available Foundation Types:
  • Basement
  • Crawlspace - * $395.00
  • Slab - * $395.00
  • Stem Wall Slab - * $395.00

* May require additional drawing time.

Plan Pricing

  • PDF File: $2,370.00
  • 3 Sets: $2,505.00
  • CAD File: $3,370.00
  • Right Reading Reverse: $225.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $65.00
* prices shown w/o any discounts applied

Plan 81840 | Order Code: 00WEB | Elevation

Reverse Plan


Plan 81840 | Order Code: 00WEB | Lower Floor Plan

Reverse Plan


Plan 81840 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Plan 81840 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Plan 81840 | Order Code: 00WEB | Rear Elevation

Specifications

  • Total Living Area: 4101
  • Lower Living Area: 1658
  • Main Living Area: 1658
  • Upper Living Area: 785
  • Garage Area: 553
  • Garage Type: Attached
  • Garage Bays: 2
  • House Width: 60'4
  • House Depth: 51'10
  • Number of Stories: 2
  • Bedrooms: 5
  • Full Baths: 3
  • Half Baths: 1
  • Max Ridge Height: 28'3 from Front Door Floor Level
  • Primary Roof Pitch: 10:12
  • Roof Load: 55 psf
  • Roof Framing: Truss
  • Formal Dining Room: Yes
  • FirePlace: Yes
  • 1st Floor Master: Yes
  • Main Ceiling Height: 9'
  • Upper Ceiling Height: 8'

Available Foundation Types:

  • Basement
  • Crawlspace - $395.00
  • Slab - $395.00
  • Stem Wall Slab - $395.00

Plan Pricing

  • PDF File: $2,370.00
  • 3 Sets: $2,505.00
  • CAD File: $3,370.00
  • Right Reading Reverse: $225.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $65.00

** Please note that a PDF File is included with a 3 Set Order**



**All plans by this designer are being updated to IRC 2015 starting on March 13, 2023. This plan may be delayed by 4 business days before shipping.**
