Garage-Living Apartment Plan 84927 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 835 Total Living Area
  • 40 Main Level
  • 795 Upper Level
  • 1 Half Bath(s)
  • 7 Car Garage
  • 90'0 Wide x 40'0 Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $1,199.00
  • 5 Sets plus PDF File: $1,494.00
  • CAD File: $1,798.00
  • CAD File Unlimited Build: $2,198.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Materials List: $299.00
  • Right Reading Reverse: $299.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $59.00
* prices shown w/o any discounts applied

Garage-Living Plan 84927 | Order Code: 00WEB | Elevation

Reverse Plan


Garage-Living Plan 84927 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage-Living Plan 84927 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Garage-Living Plan 84927 | Order Code: 00WEB | Rear Elevation

Specifications

  • Total Living Area: 835
  • Main Living Area: 40
  • Upper Living Area: 795
  • Garage Area: 2946
  • Garage Type: Drive Under
  • Garage Bays: 7
  • House Width: 90'0
  • House Depth: 40'0
  • Number of Stories: 2
  • Half Baths: 1
  • Max Ridge Height: 26'6 from Front Door Floor Level
  • Primary Roof Pitch: 2:12
  • Roof Framing: Unknown
  • FirePlace: Yes
  • Main Ceiling Height: 10'
  • Upper Ceiling Height: 10'

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $1,199.00
  • 5 Sets plus PDF File: $1,494.00
  • CAD File: $1,798.00
  • CAD File Unlimited Build: $2,198.00
    Unlimited Build License issued on CAD File Unlimited Build orders.
  • Materials List: $299.00
  • Right Reading Reverse: $299.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $59.00
* prices shown w/o any discounts applied

Special Features:

  • Entertaining Space
  • Open Floor Plan
  • Storage Space

Architectural Styles

Contemporary, Modern

Modern 7-Car Garage Plan 84927 with 835 Sq Ft Lounge, Fireplace, Workshop and Glass Viewing Floor

Modern Garage Plan 84927 takes luxury automotive storage to an entirely new level. Designed for serious car collectors and automotive enthusiasts, this striking Contemporary garage accommodates up to 7 vehicles while incorporating a dedicated workshop and an impressive 835-square-foot upper-level lounge. With sophisticated architectural styling, a fireplace, and a dramatic transparent viewing floor overlooking the seventh garage bay, this distinctive design combines vehicle storage with an exceptional entertainment experience.

The exterior showcases the bold character of Contemporary and Modern architecture. Clean architectural lines and sophisticated detailing create an upscale appearance that sets this garage apart from conventional vehicle storage buildings. Its distinctive design makes an impressive addition to properties where automotive collections and architectural presentation are equally important.

The spacious main level provides parking for up to seven vehicles, creating an ideal environment for displaying prized automobiles, maintaining a collection, or protecting valuable vehicles from the elements. The generous garage arrangement offers dedicated space for both everyday parking and enthusiast-oriented automotive activities.

A separate shop area provides convenient space for organizing tools, equipment, and automotive supplies. Whether maintaining a collector vehicle, completing routine projects, or simply keeping equipment organized, this dedicated workspace helps separate workshop activities from the principal parking areas.

Additional main-level conveniences include a bathroom, mechanical room, and storage room. These practical features support the garage's specialized functions while providing useful accommodations for extended periods spent working on vehicles or enjoying the collection.

Upstairs, the spacious 835-square-foot lounge creates a private destination for relaxation and entertaining. A fireplace adds warmth and architectural character, transforming the upper level into an inviting gathering place for fellow automotive enthusiasts, family members, and visiting friends.

The lounge's most distinctive feature is its transparent plexiglass viewing floor positioned above the seventh garage bay. This dramatic architectural element allows guests to look directly down at the vehicle displayed below, creating a remarkable connection between the entertainment space and the automotive collection.

With seven-car capacity, a dedicated workshop, practical support rooms, and an extraordinary upper-level lounge, Garage Plan 84927 offers an exceptional solution for collectors seeking more than conventional parking. Its combination of Modern architecture and specialized entertainment features creates a distinctive automotive retreat designed around a passion for cars.
