Garage-Living Apartment Plan 86903 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 628 Total Living Area
  • 628 Upper Level
  • 1 Bedrooms
  • 1 Full Bath(s)
  • 2 Car Garage
  • 28'0 Wide x 26'0 Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $699.00
  • 1 Set: $575.00
  • 5 Sets: $699.00
  • PDF File Unlimited Build: $1,698.00
  • CAD File: $1,299.00
  • Materials List: $150.00
  • Right Reading Reverse: $299.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $50.00
* prices shown w/o any discounts applied

Garage-Living Plan 86903 | Order Code: 00WEB | Elevation

Reverse Plan


Garage-Living Plan 86903 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage-Living Plan 86903 | Order Code: 00WEB | Second Floor Plan

Reverse Plan

Specifications

  • Total Living Area: 628
  • Upper Living Area: 628
  • Garage Type: Drive Under
  • Garage Bays: 2
  • House Width: 28'0
  • House Depth: 26'0
  • Number of Stories: 1
  • Bedrooms: 1
  • Full Baths: 1
  • Max Ridge Height: 27 from Front Door Floor Level
  • Primary Roof Pitch: 8.5:12
  • Roof Load: 30 psf
  • Roof Framing: Truss
  • Porch: 41 sq ft
  • Main Ceiling Height: 9'0
  • Upper Ceiling Height: 8'0

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $699.00
  • 1 Set: $575.00 **
  • 5 Sets: $699.00
  • PDF File Unlimited Build: $1,698.00
  • CAD File: $1,299.00
  • Materials List: $150.00
  • Right Reading Reverse: $299.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $50.00

** 1 Set order does not include a License-To-Build. For bidding purposes only. Customer can upgrade order within 90 days.

The wall between the living room and closet is a load bearing wall.

* prices shown w/o any discounts applied

Architectural Styles

Country, European, Traditional

Country European Traditional Garage Apartment House Plan with 628 Sq Ft, 1 Bed, 1 Bath, 2 Car Garage

Discover the charm and functionality of this Country, European, and Traditional style garage apartment house plan, offering 628 square feet of well-designed living space. Perfect as a guest house, vacation cottage, or independent living suite, this plan features one comfortable bedroom, a full bathroom, and a practical two-car drive-under garage—all thoughtfully arranged for convenience and comfort.

The exterior showcases classic architectural details with a welcoming porch and a compact footprint, ideal for a variety of lot sizes or scenic locations. Its inviting entry leads you upstairs to the main living area, where natural light and purposeful design create a bright, open atmosphere.

The main living floor is designed for easy living, boasting a spacious living room that flows seamlessly into the kitchen area. Whether you're hosting guests or enjoying a quiet night in, the open-concept layout maximizes every inch, making entertaining and everyday life a breeze.

The private bedroom ensures restful nights, while the full bath offers modern comfort. An adjacent laundry area on the garage level adds extra convenience, keeping chores out of sight but close at hand.

Bonus features include a dedicated entryway, thoughtfully separated laundry room, and direct access to the two-car garage—perfect for vehicles, storage, or hobby space. Step out onto the rear deck for grilling, relaxing, or simply soaking in the surrounding views, making this plan a true retreat for any setting.

With a slab foundation option, sturdy truss roof framing, and a manageable house width and depth, this garage apartment plan is well-suited for families seeking guest accommodations, individuals desiring a cozy primary residence, or anyone dreaming of a lakeside or mountain getaway. Experience the flexibility, style, and comfort this versatile house plan brings to everyday living.
