Garage-Living Apartment Plan 40823 | Order Code: 00WEB

FamilyHomePlans.com
800-482-0464

Click-To-Print This Page

Specifications

  • 650 Total Living Area
  • 650 Main Level
  • 1 Bedrooms
  • 1 Full Bath(s)
  • 2 Car Garage
  • 23'0 Wide x 28'3 Deep
Available Foundation Types:
  • Slab

Plan Pricing

  • PDF File: $950.00
  • 5 Sets: $1,115.00
  • 5 Sets plus PDF File: $1,157.00
  • CAD File: $1,250.00
  • Materials List: $368.75
  • Right Reading Reverse: $150.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $35.00
* prices shown w/o any discounts applied

Garage-Living Plan 40823 | Order Code: 00WEB | Elevation

Reverse Plan


Garage-Living Plan 40823 | Order Code: 00WEB | First Floor Plan

Reverse Plan


Garage-Living Plan 40823 | Order Code: 00WEB | Second Floor Plan

Reverse Plan


Garage-Living Plan 40823 | Order Code: 00WEB | Rear Elevation

Specifications

  • Total Living Area: 650
  • Main Living Area: 650
  • Garage Area: 650
  • Garage Type: Drive Under
  • Garage Bays: 2
  • House Width: 23'0
  • House Depth: 28'3
  • Number of Stories: 2
  • Bedrooms: 1
  • Full Baths: 1
  • Max Ridge Height: 24'10 from Front Door Floor Level
  • Primary Roof Pitch: 2.5:12
  • Roof Framing: Stick
  • Porch: 126 sq ft
  • Main Ceiling Height: 9'4
  • Vaulted Ceiling: Yes

Available Foundation Types:

  • Slab

Plan Pricing

  • PDF File: $950.00
  • 5 Sets: $1,115.00
  • 5 Sets plus PDF File: $1,157.00
  • CAD File: $1,250.00
  • Materials List: $368.75
  • Right Reading Reverse: $150.00
    All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
  • Additional Sets: $35.00

Materials List may take 3-5 weeks to fulfill depending on availability.

* prices shown w/o any discounts applied

Special Features:

  • 2nd Floor Balcony
  • Deck or Patio
  • Entertaining Space
  • Narrow Lot
  • Open Floor Plan
  • Pantry
  • Storage Space

Architectural Styles

Contemporary, Modern

Modern Garage Apartment Plan 40823 with 650 Sq Ft, 1 Bedroom, 1 Bath, 2-Car Garage and Private Deck

Modern Garage Apartment Plan 40823 combines contemporary architecture with efficient living space and practical two-car parking. This stylish carriage house features a 650-square-foot upper-level apartment with 1 bedroom, 1 full bathroom, an open-concept living area, and a private outdoor deck. Below, a spacious drive-under garage accommodates two vehicles, making this narrow-lot-friendly design an excellent choice for guest accommodations, extended-family living, or a potential accessory dwelling unit (ADU).

The exterior showcases bold Modern styling with an angled roofline, expansive windows, and clean architectural details. Dark gray siding paired with richly stained wood garage doors and decking creates a sophisticated contemporary appearance. Metal railings along the exterior staircase and upper deck introduce an attractive industrial influence, while floor-to-ceiling windows fill the apartment with natural light.

The ground-level garage features an interior measuring approximately 22 feet wide by 27 feet deep. A single 16-foot-wide by 8-foot-high overhead door provides convenient access for two vehicles. Rear windows and a window above the personnel door bring natural daylight into the garage, creating a more welcoming environment for parking, storage, or workshop activities.

With a building footprint approximately 23 feet wide by 28 feet 3 inches deep, excluding the deck and exterior staircase, this detached garage apartment is especially appealing for properties where lot width is limited.

An exterior staircase provides independent access to the upper-level apartment without requiring guests to enter through the garage. This thoughtful arrangement creates separation between parking and residential activities while offering additional privacy from the main residence.

Upstairs, the open-concept living area brings the kitchen and gathering space together in a comfortable arrangement. A generous kitchen island provides preparation space and casual seating, while the sink and refrigerator are positioned along one wall to preserve an open, functional layout.

The bedroom measures approximately 12 feet by 11 feet and includes a closet. A full bathroom features a tub and shower combination, spacious vanity, and convenient linen storage. These practical amenities make the apartment suitable for comfortable everyday living.

The elevated outdoor deck extends the living experience beyond the interior, offering an inviting place for morning coffee, relaxation, or entertaining. Where local regulations permit, this versatile design may serve as an ADU, guest apartment, or rental residence.

Garage Apartment Plan 40823 delivers a distinctive combination of Modern architecture, private residential accommodations, and convenient two-car parking. Confirm local zoning and ADU requirements before construction.
