House Plan 10492

• PDF Study Set: $1,400.00
  Get your plans fast! A PDF Study Set is a complete set of plans stamped NOT FOR CONSTRUCTION. Not considered a license-to-build. Great for bidding purposes. Customer can upgrade within 90 days.
• PDF File: $1,600.00
• 1 Set: $1,400.00
• 5 Sets: $1,500.00
• 5 Sets plus PDF File: $1,700.00
• Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Materials List: $300.00
• Additional Sets: $100.00

Plans are not to be sold in New Jersey or Maryland.

Available Foundation Types:

• Slab : No Additional Fee

Available Exterior Wall Types:

• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	4441 sq ft
Main Living Area:	2409 sq ft
Upper Living Area:	2032 sq ft
Garage Area:	690 sq ft
Garage Type:	Attached
Garage Bays:	3
Foundation Types:	Slab
Exterior Walls:	2x6
House Width:	52'
House Depth:	70'
Number of Stories:	2
Bedrooms:	4
Full Baths:	3
Max Ridge Height:	26'6 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Load:	37 psf
Roof Framing:	Stick
Deck:	215 sq ft
Formal Dining Room:	Yes
FirePlace:	Yes
Main Ceiling Height:	8'
Upper Ceiling Height:	8'

Special Purpose Rooms Highlight Distinctive Design

With a special television room plus a family room and an upstairs sitting room, there's plenty of opportunity for everyone in the family to enjoy personal activities and pursuits. The well-designed kitchen adjoins the formal dining room and also has its own dining nook with lots of windows for sunny family breakfasts and lunches. Both the living room and familly room open onto patios for indoor/outdoor entertaining. The second floor sitting room, complete with a fireplace and warm hearth, adjoins the spacious master suite with its six-piece bath complete with Roman tub and oversized, walk-in closet. Two smaller bedrooms flank a walk-through bath to complete the second floor of this roomy, family home.

Exterior Elevations Scaled drawings of the front, rear, sides of the home. Information pertaining to the exterior finish materials, roof pitches and exterior height dimensions.

Typical Wall Section This section will address insulation, roof components, and interior and exterior wall finishes. Your plans will be designed with either 2x4 or 2x6 exterior walls, but most professional contractors can easily adapt the plans to the wall thickness you require.

Fireplace Details If the home you have chosen includes a fireplace, the fireplace detail will show typical methods to construct the firebox, hearth and flue chase for masonry units, or a wood frame chase for a zero-clearance unit. Available for most plans.

Foundation Plan These plans will accurately dimension the footprint of your home including load bearing points and beam placement if applicable. The foundation style will vary from plan to plan.

Roof Plan The information necessary to construct the roof will be included with your home plans. Some plans will reference roof trusses, while many others contain schematic framing plans. These framing plans will indicate the lumber sizes necessary for the rafters and ridgeboards based on the designated roof loads.

Typical Cross Section A cut-away cross-section through the entire home shows your building contractor the exact correlation of construction components at all levels of the house. It will help to clarify the load bearing points from the roof all the way down to the basement. Available for most plans.

Detailed Floor Plans The floor plans of your home accurately dimension the positioning of all walls, doors, windows, stairs and permanent fixtures. They will show you the relationship and dimensions of rooms, closets and traffic patterns. The schematic of the electrical layout may be included in the plan.

Stair Details If stairs are an element of the design you have chosen, the plans will show the necessary information to build these, either through a stair cross section, or on the floor plans.
