House Plan 55701
Mediterranean Style with 7 Bed, 9 Bath, 4 Car Garage | Plan 55701
sq ft
11027beds
7baths
8.5bays
4width
158'depth
128'
Plan Pricing from $2,900.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Additional Notes
CEILING HEIGHT:Livingroom/Foyer- Two Story
Kitchen/Family Rm/Media/Excercise/Lounge- 11'4"
Master Bedroom- Boxed from 9'10"- 10'6"-11'2"
Dining/Library- 10'8"- 11'4"
Bedrooms 2,3,4,5- 9'10"
Master Bath- 9'10"
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 11027 sq ft |
| Main Living Area: | 6956 sq ft |
| Upper Living Area: | 4071 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 4 |
| Foundation Types: | Slab |
| Exterior Walls: | Concrete |
| House Width: | 158' |
| House Depth: | 128' |
| Number of Stories: | 2 |
| Bedrooms: | 7 |
| Full Baths: | 8 |
| Half Baths: | 1 |
| Max Ridge Height: | 35' from Front Door Floor Level |
| Primary Roof Pitch: | 4:12 |
| Roof Load: | 55 psf |
| Roof Framing: | Unknown |
| Formal Dining Room: | Yes |
| FirePlace: | Yes |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 9' |
| Upper Ceiling Height: | 9' |
Plan Description
Covered Entry with round columns Foyer open to above with grand staircase Living Room open to above with access to Rear Covered Patio Sliding doors to Lounge with bar Dining Room with French doors to 3 entrances and Serving Room/Butler's Pantry Family Room with access to Covered Patio and open to Breakfast Room and Kitchen Kitchen with snack bar, island and walkin Pantry Library woth coffered ceiling Living Room with Kitchenette for Maid's Quarters Maid's Bedroom with walkin closet and private bath Laundry Room with ample counterspace and built-in ironing board Exercise Room with French doors to Rear Patio Steam Room Media Room Princess Suite with whirlpool tub, corner shower and walkin closet Elevator Master Suite with Sitting Area, coffered ceiling and access to Covered Balcony Two walkin closets Master Bath with whirlpool tub and shower -- two baths Bedrooms 2,3,4 and 5 with walkin closets and private baths
