House Plan 57845
Pool House Plan or Cabana at Family Home Plans | Guest House | Plan 57845
sq ft
701beds
1baths
1bays
0width
36'depth
33'
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 701 sq ft |
| Main Living Area: | 701 sq ft |
| Garage Type: | None |
| See our garage plan collection. If you order a house and garage plan at the same time, you will get 10% off your total order amount. | |
| Foundation Types: | Crawlspace - * $300.00 Slab |
| Exterior Walls: | 2x4 |
| House Width: | 36' |
| House Depth: | 33' |
| Number of Stories: | 1 |
| Bedrooms: | 1 |
| Full Baths: | 1 |
| Max Ridge Height: | 19' from Front Door Floor Level |
| Primary Roof Pitch: | 8:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss and/or Stick |
| Porch: | 400 sq ft |
| Main Ceiling Height: | 9' |
| Vaulted Ceiling: | Yes |
Plan Description
Pool House Plan or Cabana at Family Home Plans | Guest House
Open Layout with a designated sleeping area / living area and central kitchen. The kitchen has a view with lots of windows and a large kitchen island. No cabana would be complete without an open wet bar with seating for poolside guests. The outside storage is connected t the bathroom.What's Included?
