House Plan 59317
Craftsman Style, 704 Sq Ft, 1 Bed, 2 Bath | Plan 59317
sq ft
704beds
1baths
0.5bays
0width
36'depth
30'
Plan Pricing from $625.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 704 sq ft |
| Main Living Area: | 704 sq ft |
| Garage Type: | None |
| See our garage plan collection. If you order a house and garage plan at the same time, you will get 10% off your total order amount. | |
| Foundation Types: | Crawlspace - * $300.00 Slab |
| Exterior Walls: | 2x4 |
| House Width: | 36' |
| House Depth: | 30' |
| Number of Stories: | 1 |
| Bedrooms: | 1 |
| 3/4 Baths: | 1 |
| Half Baths: | 1 |
| Max Ridge Height: | 19' from Front Door Floor Level |
| Primary Roof Pitch: | 8:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss and/or Stick |
| Porch: | 376 sq ft |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 9' |
Plan Description
Craftsman Style, 704 Sq Ft, 1 Bed, 2 Bath
Cottage, Craftsman Style House Plan 59317 with 704 Sq Ft, 1 Bed, 2 BathWhat's Included?
