Multi-Family Plan 43713

• PDF File: $2,615.00
• 1 Set: $1,095.00 **
• 5 Sets plus PDF File: $1,665.00
• CAD File: $2,855.00
  Single Build License issued on CAD File orders.
• Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Right Reading Reverse: $465.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $70.00

** 1 Set order does not include a License-To-Build. For bidding purposes only. Customer can upgrade order within 90 days.

Additional Notes

Unit A
1st Floor: 1277 sq ft
Daylight Bsmt: 250 sq ft
Garage: 595 sq ft
Bedrooms: 3
Full Baths: 2
Garage Bays: 2

Unit B
1st Floor: 1277 sq ft
Daylight Bsmt: 250 sq ft
Garage: 595 sq ft
Bedrooms: 3
Full Baths: 2
Garage Bays: 2

Available Foundation Types:

• Basement : No Additional Fee
  Total Living Area may increase with Basement Foundation option.

Available Exterior Wall Types:

• 2x4: $580.00
  (Please call for drawing time.)
• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	3054 sq ft
Lower Living Area:	500 sq ft
Main Living Area:	2554 sq ft
Garage Area:	1190 sq ft
Garage Type:	Attached
Garage Bays:	4
Foundation Types:	Basement
Exterior Walls:	2x4 - * $580.00 2x6
House Width:	72'0
House Depth:	47'0
Number of Stories:	2
Bedrooms:	6
Full Baths:	4
Max Ridge Height:	29'2 from Front Door Floor Level
Primary Roof Pitch:	2:12
Roof Load:	25 psf
Roof Framing:	Truss
Main Ceiling Height:	9'

* May require additional drawing time.

Special Features:

• 2nd Floor Balcony
• Entertaining Space
• Mudroom
• Open Floor Plan
• Pantry
• Rear Porch
• Storage Space

Charming Duplex Plan with 3054 Sq Ft, 6 Beds, 4 Baths and a 4 Car Garage

Duplex Plan With Drive-Under Garage (Plan 43713) has 3,054 square feet of living space. That total includes both units. The Contemporary style of this duplex home plan's panel siding and cable rail balconies make for a charming addition to any new development or neighborhood. The wide, expansive nature of this duplex makes it possible for large families to enjoy busy city living. Each unit features a split-level entry and two garage bays each.

Duplex Plan With Drive-Under Garage For a Sloped Lot

Sitting on a sloped lot, this plan is more versatile and can fit on a special type of lot that most duplex plans cannot. The lower daylight basement floor encompasses the garage, utility room, and a mud hall that is perfect for separating dirty clothes from the main living areas upstairs. Leave bulky coats in the closet in the mud hall. When it's time to go, utilize the bench seating so you can pull on those heavy boots.

The second floor has a unique feature that an ordinary duplex does not; high 12’ ceilings in the master suite and great room. Occupants love the tall windows in the great room combined with the balcony where you can sit and enjoy your coffee in the morning. Not only that, but the natural light from these windows filters throughout the living space. Notice the open floor plan among the great room and dining area. The kitchen is open to the dining room, being separated by a mere eating bar. The walk-in pantry is a nice touch to each kitchen and shares a wall with the rear covered porch.

Duplex Plan With 3 Bedrooms in Each Unit

Towards the rear of the main upper floor are the two additional bedrooms that share a hall bathroom. Each guest bedroom has adequate closet space. Couples with children will be drawn to this duplex floor plan because it offers so many bedrooms. Plus, retired couples will choose this plan because the extra bedrooms are great to use for an office or guest room. The owner's suite is not far away, and it has everything you need to be comfortable.

In conclusion, this 6 bedroom duplex plan has great master bedrooms with walk-in closet and double vanity, plus two covered outdoor areas, open living space, and storage closets. The drive-under garage is a great solution for those who live in a cold climate as well.

Artist's Rendering: An artist's drawing of the home, usually viewed from the front.

Elevations: Drawings which show the front, sides, and rear of the home, including exterior materials, trim sizes, roof pitches, etc.

Main Floor Plan: Shows the placement and dimensions of all walls, doors, and windows. Includes the location of beams, ceiling heights, pertinent interior elevations, etc.

Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.

Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details.

Basement Plan (if any): Included if the plan has a basement alternative. Shows all basement details. Plans which include alternate basement stair location or main basement stair will include a basement plan. Other plans can be modified to include a basement foundation.

Roof Framing Plan: Shows roof outlines, conventional framing and/or trusses, beams, roof framing details, etc.

Details: Drawings which show specific details such as fireplaces, stairways, decks, etc.

Section: A drawing of a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.

Electrical Plan: A schematic layout of all lighting and electrical outlets.
