Multi-Family Plan 43741

• PDF File: $2,615.00
• 1 Set: $1,095.00 **
• 5 Sets plus PDF File: $1,665.00
• CAD File: $2,855.00
  Single Build License issued on CAD File orders.
• Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Right Reading Reverse: $465.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $70.00

** 1 Set order does not include a License-To-Build. For bidding purposes only. Customer can upgrade order within 90 days.

Available Foundation Types:

• Basement : No Additional Fee
  Total Living Area may increase with Basement Foundation option.

Available Exterior Wall Types:

• 2x4: $580.00
  (Please call for drawing time.)
• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	3936 sq ft
Lower Living Area:	352 sq ft
Main Living Area:	2418 sq ft
Upper Living Area:	1166 sq ft
Garage Area:	992 sq ft
Garage Type:	Attached
Garage Bays:	4
Foundation Types:	Basement
Exterior Walls:	2x4 - * $580.00 2x6
House Width:	54'0
House Depth:	51'0
Number of Stories:	2
Bedrooms:	6
Full Baths:	4
Half Baths:	2
Max Ridge Height:	35'5 from Front Door Floor Level
Primary Roof Pitch:	2:12
Roof Load:	20 psf
Roof Framing:	Truss
1st Floor Master:	Yes
Main Ceiling Height:	9'
Upper Ceiling Height:	8'

* May require additional drawing time.

Special Features:

• Deck or Patio
• Entertaining Space
• Front Porch
• Open Floor Plan
• Pantry
• Storage Space

Wrapped in a modern exterior is this attractive hillside townhouse plan. Each unit is the same so only one is described. Up the flight of stairs from street level you enter a split-entry foyer. Heading down will bring you to the basement level where a mud hall provides access to the attached 2 car garage and storage. Following the stairs upwards from the entry, leads to the great room and main living area of the home. A sliding glass door opens the living area to the back covered patio. An island helps to separate the kitchen from the dining room while adding to the information seating with the flush eating bar. Off the dining room, a short hallway leads past the laundry room and a powder bath. At the end is the owners' suite which features a walk-in closet and private bath with twin sinks. Well separated from the main floor master, two additional bedrooms are on the second floor. Each features a vaulted ceiling along with access to a compartmentalized bathroom.

Artist's Rendering: An artist's drawing of the home, usually viewed from the front.

Elevations: Drawings which show the front, sides, and rear of the home, including exterior materials, trim sizes, roof pitches, etc.

Main Floor Plan: Shows the placement and dimensions of all walls, doors, and windows. Includes the location of beams, ceiling heights, pertinent interior elevations, etc.

Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.

Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details.

Basement Plan (if any): Included if the plan has a basement alternative. Shows all basement details. Plans which include alternate basement stair location or main basement stair will include a basement plan. Other plans can be modified to include a basement foundation.

Roof Framing Plan: Shows roof outlines, conventional framing and/or trusses, beams, roof framing details, etc.

Details: Drawings which show specific details such as fireplaces, stairways, decks, etc.

Section: A drawing of a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.

Electrical Plan: A schematic layout of all lighting and electrical outlets.
