3 Car Garage Plan 44139
Traditional Style 3 Car Garage | Plan 44139
Click Any Image For Gallery
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Garage Area: | 1014 sq ft |
| Garage Type: | Detached |
| Garage Bays: | 3 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x4 2x6 - * $299.00 ICF - * $750.00 |
| House Width: | 39' |
| House Depth: | 26' |
| Number of Stories: | 1 |
| Max Ridge Height: | 14'6 from Front Door Floor Level |
| Primary Roof Pitch: | 2:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss |
| Main Ceiling Height: | 9' |
Plan Description
Traditional Style 3 Car Garage
Traditional Style Garage Plan 44139 with 3 Car GarageWhat's Included?
Our blueprints include:
Cover Sheet: Shows the front elevation and typical notes and requirements.
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements.
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible. Detached garage plans may not include an electrical plan. Please call to verify.
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
Roof Plan
Typical wall section
Typical stair section
Cabinets are shown on all plans
Modifications
1. Complete this On-Line Request Form
2. Print, complete and fax this PDF Form to us at 1-800-675-4916.
3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.
Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.
We Work Fast!
When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!
We look forward to hearing from you!
Start today planning for tomorrow!
Q & A
Ask the Designer any question you may have. NOTE: If you have a plan modification question, please click on the Plan Modifications tab above.
Previous Q & A
A: Good morning. The main level plate line is at 9' and the front wall plate line is a little over 13' and yes the roof pitch is 2:12/slope. Truss roof per local manufacturer. Let me know if they have any more questions :)
A: It has a 9' rear wall and yes it is vaulted ceilings inside. The rest of the info will be on the construction set.
A: it is 13'-4" high
A: Wayne you will need to have 1' taller walls for a 9' garage door to work.
A: We call out roof trusses per manufacturer and the inside ceiling height would be 8'-2"
A: Alan the truss manufacturer will have to design your trusses. We call out the shingles as asphalt but others have built it with a metal roof as well.
A: THIN SET STONE
Common Q & A
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
