4 Car Garage Plan 49163

• PDF File: $440.00
• CAD File: $540.00
  Single Build License issued on CAD File orders.
• Materials List: $60.00
• Right Reading Reverse: $70.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

The PDF file will also be included with the purchase of the CAD file.

Plan Options:

• Unlimited Build License Option: $750.00

Available Foundation Types:

• Stem Wall Slab : No Additional Fee

Available Exterior Wall Types:

• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Garage Area:	2160 sq ft
Garage Type:	Detached
Garage Bays:	4
Foundation Types:	Stem Wall Slab
Exterior Walls:	2x6
House Width:	60
House Depth:	36
Number of Stories:	1
Full Baths:	1
3/4 Baths:	1
Max Ridge Height:	20 from Front Door Floor Level
Primary Roof Pitch:	5:12
Roof Load:	40 psf
Roof Framing:	Truss
Main Ceiling Height:	10
Upper Ceiling Height:	0
Vaulted Ceiling:	Yes
Tray Ceiling:	Yes

Garage Plan 49163 with 2,160 Sq Ft, 4 Car Garage

Discover the versatility and robust design of Garage Plan 49163, an exceptional garage plan offering a spacious 2,160 square feet of premium vehicle storage and workspace. This detached garage is perfectly suited for car enthusiasts, hobbyists, or anyone seeking superior garage amenities and flexible utility options.

With its impressive 60-foot width and 36-foot depth, this garage plan exudes curb appeal through a balanced roofline, modern truss framing, and clean architectural lines. The elevation showcases both function and style, making it an attractive addition to your property while providing substantial storage for up to four vehicles.

Step inside to experience the generous open bay layout, ideal for multiple cars, large trucks, recreational vehicles, or even a workshop. The plan offers a vaulted ceiling reaching 10 feet in height, which not only enhances maneuverability but also allows for automotive lifts or tall storage solutions. Tray ceiling details add a touch of sophistication to the overall space.

Unique among garage plans, Plan 49163 features both a full bath and a three-quarter bath, delivering comfort and convenience for extended projects or when entertaining guests. These bathroom amenities elevate the garage into a multifunctional outbuilding, accommodating everything from classic car restoration to weekend gatherings.

Additional highlights include the stem wall slab foundation option, ensuring long-lasting durability and straightforward construction. With a max ridge height of 20 feet and a 5:12 roof pitch, the design is both practical and visually appealing.

Wide door access and thoughtful window placements invite abundant natural light, while the detached layout offers privacy and flexibility in site planning. Whether you use the space for vehicle storage, a home-based business, or a personal workshop, Garage Plan 49163 provides unmatched adaptability.

This garage plan is ideal for homeowners seeking premium garage storage, builders looking to expand property utility, or anyone needing an attractive, functional outbuilding to complement their residential lifestyle.

These blueprints will include building specifications, foundation plan, floor plans, exterior elevations, electrical plans, interior cabinet elevations, wall sections and stair details. Some of the larger plans will have additional details.

All plans have been drawn to meet the requirements of the national building codes. Your builder will be able to determine if minor modifications may need to be made to the plans to meet the local building code requirements including any subdivision requirements.

Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
