House Plan 52040
Southern Style, 2800 Sq Ft, 3 Bed, 2 Bath | Plan 52040
sq ft
2800beds
3baths
2bays
3width
103'depth
80'
Plan Pricing from $1,650.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Sorry, but this plan cannot be sold in the following zip codes: 30041, 30501, 30504, 30506, 30542, or 30566.
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 2800 sq ft |
| Main Living Area: | 2800 sq ft |
| Unfinished Basement Area: | 2800 sq ft |
| Garage Area: | 758 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 3 |
| Foundation Types: | Walkout Basement |
| Exterior Walls: | 2x4 |
| House Width: | 102'3 |
| House Depth: | 79'1 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Max Ridge Height: | 25'3 from Front Door Floor Level |
| Primary Roof Pitch: | 12:12 |
| Roof Framing: | Stick |
| Porch: | 413 sq ft |
| FirePlace: | Yes |
| Main Ceiling Height: | 10' |
| Vaulted Ceiling: | Yes |
| Tray Ceiling: | Yes |
Special Features:
Plan Description
New American Lake House Plan with Vaulted Ceilings, Walkout Basement & Angled 3-Car Garage
This beautifully designed New American-style lake house plan offers the perfect blend of rustic charm and modern living, ideal for scenic properties with a sloped lot or hillside terrain.The main level features 2,800 square feet of heated living space, including 3 spacious bedrooms, 3 full bathrooms, and a 3-car garage set at a unique 45-degree angle—adding both function and curb appeal.
Step into an open floor plan designed for effortless entertaining and everyday comfort. The great room boasts vaulted ceilings and a cozy fireplace, creating a warm and inviting space that flows seamlessly into the dining area and kitchen.
Enjoy the outdoors year-round with a covered rear porch featuring an outdoor fireplace, plus an expansive deck—perfect for lakeside or mountainside living.
This house plan includes an optionally finished walkout basement, adding even more flexibility and value. The lower level provides:
2 additional bedrooms
2 full bathrooms
A large rec room with a wet bar and island
A laundry room
Generous storage space
This smartly designed lake house plan with a walkout basement is ideal for building on rugged terrain, maximizing your views, and creating private living zones for guests or extended family.
Whether you're building your forever home, a vacation getaway, or a multi-generational family retreat, this open-concept home with vaulted ceilings, a 3-car angled garage, and walkout lower level is ready to deliver beauty, functionality, and long-term comfort.
