House Plan 55714
One-Story Style with 3 Bed, 2 Bath, 2 Car Garage | Plan 55714
sq ft
1671beds
3baths
2bays
2width
41'depth
58'
Plan Pricing from $1,150.00
Plan Pricing
Need Prints?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Additional Notes
Total Under Roof: 2,280Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1671 sq ft |
| Main Living Area: | 1671 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Slab |
| Exterior Walls: | Concrete |
| House Width: | 41' |
| House Depth: | 58' |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Max Ridge Height: | 19' from Front Door Floor Level |
| Primary Roof Pitch: | 5:12 |
| Roof Load: | 30 psf |
| Roof Framing: | Truss |
| Porch: | 162 sq ft |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 8' |
