House Plan 59146
Traditional Craftsman House Plan 59146 with 1509 Sq Ft, 3 Beds, 2 Baths and a 2 Car Garage
sq ft
1509beds
3baths
2bays
2width
61'depth
48'
click for more images
FHP Low Price Guarantee
If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1509 sq ft |
| Main Living Area: | 1509 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Basement Crawlspace Stem Wall Slab |
| Exterior Walls: | 2x4 |
| House Width: | 61' |
| House Depth: | 47'4 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Max Ridge Height: | 22'1 from Front Door Floor Level |
| Primary Roof Pitch: | 8:12 |
| Roof Load: | 30 psf |
| Roof Framing: | Stick |
| Porch: | 274 sq ft |
| FirePlace: | Yes |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 9' |
Special Features:
Plan Description
Traditional Craftsman House Plan 59146 with 1509 Sq Ft, 3 Beds, 2 Baths and a 2 Car Garage
Traditional Craftsman House Plan 59146 is a timeless design which has been a popular choice at Family Home Plans for over 15 years. The functional split floor plan layout has many of the features that your family desires. For example, comfortable outdoor living space is paired with cozy interior features like the gas log fireplace. With a total of 1,509 square feet of living space, 3 bedrooms, and 2 bathrooms, this construction plan is both budget-friendly and attractive.
Traditional Craftsman House Plan With Covered Back Porch
Are you ready to take a home tour of Traditional Craftsman House Plan 59146? Firstly, we enter the main living space. Vaulted ceiling in the great room really makes it feel spacious and lofty. Gather on your couch in front of the gas log fireplace on chilly fall evenings. When company comes over, guests will enjoy seeing your family memories displayed on the built-in cabinets. The floor plan is semi-open which really sets it apart from your average new construction home plan.
Secondly, the kitchen is compact and easy to maintain. For those who prefer a smaller-scale and more traditional kitchen setup, this one fits the bill. Everything you need is included such as major appliances, and there is a pantry cabinet included for storage. Thirdly, you have options when it comes to enjoying a meal. Sit down in the adjoining eating area which measures 10'10 wide by 10'6 deep. Or, step through the back door and grill hamburgers on the covered back porch.
3 Bedroom Craftsman Ranch Home Plan
Storage and laundry are always a concern of prospective homebuyers. Traditional Craftsman House Plan 59146 does not disappoint. In fact, it offers several storage solutions throughout the home. Check out the right side hallway where we find a broom closet to store cleaning supplies and a separate linen closet. Find another hall closet on the opposite side of the home and a storage room in the garage. Lastly, the laundry room is a generous size when it comes time to get the chores done.
Two children's bedrooms are located on the right side of the floor plan. Each has the same amount of space and a good-sized closet. The kiddos share the guest bathroom, and it includes a tub/shower combination. Far away on the opposite side of the house we find the master suite. Mom and Dad will love the tray ceiling, garden tub, double sink, and TWO walk-in closets.
What's Included?
Floor Plan/Plans (scale: 1/4" = 1' - 0")
Cabinet Elevations (scale: 3/8" = 1' - 0")
Electrical Plan Layout with Electrical Symbols Legend
Exterior Elevations (typically 4)
Typical Exterior Wall Section (scale: 3/4" = 1' - 0")
Section Thru Building (usually 1/2" = 1' - 0", transverse section)
Roof Drainage Plan (scale: 1/8" = 1' - 0")
Foundation Plan and Details (plan scale: 1/4" = 1'-0"; details: 3/4"=1'-0")
Short-form FHA/VA Specifications form
License to Build
Plans range in number of pages from 5 to 13 pages on 24" x 36" sheets. Printed on a wide-format xerox machine to guarantee quality of the prints and very good legibility. Prints are printed on white bond paper. Reproducible plans are printed on eraseable vellum.
This Plan is a USDA Rural Development Certified Plan
Modifications
Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. We believe that modification estimates should be FREE!
We provide a modification service so that you can customize your new home plan to fit your budget and lifestyle.
Simply contact the modification department via...
Email Us This is the best and quickest way to get a modification quote!
Please include your Telephone Number, Plan Number, Foundation Type, State you are building in and a Specific List of Changes.
It's as simple as that!
Cost To Build
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
** Available for U.S. only.
Q & A
Ask the Designer any question you may have. NOTE: If you have a plan modification question, please click on the Plan Modifications tab above.
Previous Q & A
A: Hello, The basement version has an extended entry hall, which raises the heated footage to approx. 1531 s.f. The basement stairwell is classified as unheated footage, so its not included in the heated footage. If you order the basement version, the extra door between garage entry and master bed door is eliminated. You walk in the entry hall from the garage, and there is then a hallway all the way to the great room. Yes, the garage slab is one step below the main level. The exact distance is to be determined onsite as needed for the slope of your lot. Its between you and your builder to determine. Thanks.
A: Hello, Beds and utility have 36"x60" windows, 36x36 over master tub, 36x12 hall bath, twin 32"x60" in great room, 32"x36" kitchen, and 48x60 in eating area. Thanks.
A: Hello, We did modify the plan for another client where we changed it to a side entry garage. We have attached an image of the front view from that modified plan. They also eliminated the offset on the front porch to make it just one gable there.. which is also reflected in this image. The attached image has a 22' wide garage. You could move the doors to the side in the field, but you would also need to enlarge the garage at least 2 feet, and 4 feet if possible to fit full size vehicles which are approx. 20 feet long. 24x24 garage size is ideal for two full size vehicles. Thanks. House Plan Gallery, Inc.
View Attached FileA: Hello, We could place kitchen counters all along the rear wall of the kitchen/eating area, then we assume you would want to remove the wall behind the pantry too. This layout is going to leave you with about 8'-6" depth, from the new rear counters to where the great room begins. So it would be tight. We would recommend taking in the rear porch to enlarge the kitchen/eating area, and provide an extra five feet depth for the table area. You could add on a new porch behind that if you prefer. If you need a modification quote, just let us know. Thanks. Modification Department
A: Hello, The width is 61'-0" outside of stud wall to outside of stud wall. Depth is 47'-4".
Common Q & A
A: Yes you can! Please click the "Modifications" tab above to get more information.
A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
FHP Low Price Guarantee
If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
FHP Low Price Guarantee
If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
click image to enlargeInfo Brochure
Photographs may show modified designs.
Elevation
Level One
Quick Specs
1509 Total Living Area1509 Main Level
3 Bedrooms
2 Full Baths
2 Car Garage
61' W x 47'4 D
Quick Specs
1509 Total Living Area3 Bedrooms
2 Full Baths
2 Car Garage
61' W x 47'4 D
Pricing
PDF File: $1,595.001 Set: $135.00
5 Sets: $1,485.00
5 Sets plus PDF File: $1,680.00
CAD File: $2,075.00
more info
Rear Elevation
Photographs may show modified designs.
