3 Car Garage Apartment Plan 74841

• PDF File: $1,045.00
• 5 Sets: $1,045.00
• 5 Sets plus PDF File: $1,350.00
• 8 Sets: $1,195.00
• CAD File: $1,495.00
  Single Build License issued on CAD File orders.

Need A Materials List?

It seems that this plan does not offer a stock materials list, but we can make one for you. Please call 1-800-482-0464, x403 to discuss further.
• Right Reading Reverse: $295.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $55.00

Available Foundation Types:

• Slab : No Additional Fee

Available Exterior Wall Types:

• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	1240 sq ft
Main Living Area:	336 sq ft
Upper Living Area:	904 sq ft
Bonus Area:	258 sq ft
Garage Type:	N/A or Unknown
Garage Bays:	3
Foundation Types:	Slab
Exterior Walls:	2x6
House Width:	57'6"
House Depth:	45'0"
Number of Stories:	1
Bedrooms:	1
Full Baths:	2
Max Ridge Height:	24'3" from Front Door Floor Level
Primary Roof Pitch:	12:12
Roof Framing:	Unknown
Formal Dining Room:	Yes
Main Ceiling Height:	9'0"
Upper Ceiling Height:	8'0"
Vaulted Ceiling:	Yes

Special Features:

• Bonus Room
• Deck or Patio
• Rear Porch

Foundation Plans: include drawings for a standard, daylight or partial basement, crawlspace, pier, or slab foundation. All necessary notations and dimensions are included. (Foundation options will vary for each plan. If the home you want does not have the type of foundation you desire, contact us to discuss having that plan created.)

Detailed Floor Plans: show the placement of interior walls and the dimensions for rooms, doors, windows, stairways, etc., of each level of the house. In some cases, the door and window dimensions and/or stair details may be on a separate page.

Exterior Elevations: show the front, rear and sides of the house, including exterior materials, details and measurements.

Wall Sections and/or Cross Sections: show details of the house as though it were cut in slices from the roof to the foundation. The cross sections specify the home's construction, insulation, flooring and roofing details.

Roof Details: show slope, pitch and location of dormers, gables and other roof elements, including clerestory windows and skylights. These details may be shown on the elevation sheet or on a s eparate diagram. Note: If trusses are used, we suggest using a local truss manufacturer to design your trusses to comply with your local codes and regulations.

Standard Construction Details: various details related to beam support, floor construction, connections, and roofing options.
