House Plan 75174

Updated Craftsman Home Plan With Carport | Plan 75174

sq ft

1657

beds

baths

bays

width

64'

depth

58'

Turn OFF Image Gallery

Add to cart

Plan Pricing from $1,095.00

Plan Pricing

PDF File: $1,095.00
5 Sets: $1,295.00
5 Sets plus PDF File: $1,395.00
CAD File: $2,095.00
Single Build License issued on CAD File orders.
CAD File Unlimited Build: $2,790.00
Unlimited Build License issued on CAD File Unlimited Build orders.

Need A Materials List?

It seems that this plan does not offer a stock materials list, but we can make one for you. Please call 1-800-482-0464, x403 to discuss further.

Right Reading Reverse: $245.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Additional Sets: $60.00

Plan Options:

3-Car Garage Option: $195.00

Available Foundation Types:

Basement : $395.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Crawlspace : $195.00
May require additional drawing time, please call to confirm before ordering.
Slab : No Additional Fee
Walkout Basement : $495.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.

Available Exterior Wall Types:

2x4: No Additional Fee
2x6: $345.00
(Please call for drawing time.)

Prices subject to approval prior to fulfillment.

Shipping Policy

Add to cart

Specifications

Total Living Area:	1657 sq ft
Main Living Area:	1657 sq ft
Bonus Area:	641 sq ft
Garage Area:	267 sq ft
Garage Type:	Carport
Garage Bays:	2
Foundation Types:	Basement - * $395.00 Total Living Area may increase with Basement Foundation option. Crawlspace - * $195.00 Slab Walkout Basement - * $495.00 Total Living Area may increase with Basement Foundation option.
Exterior Walls:	2x4 2x6 - * $345.00
House Width:	64'0
House Depth:	58'0
Number of Stories:	1
Bedrooms:	3
Full Baths:	2
Max Ridge Height:	30'8 from Front Door Floor Level
Primary Roof Pitch:	10:12
Roof Load:	20 psf
Roof Framing:	Stick
Porch:	624 sq ft
FirePlace:	Yes
Main Ceiling Height:	10'
Upper Ceiling Height:	9'

* May require additional drawing time.

Special Features:

Bonus Room
Entertaining Space
Front Porch
Open Floor Plan
Pantry
Porte Cochere
Rear Porch
Storage Space

Plan Description

Updated Craftsman Home Plan With Carport

Welcome to Updated Craftsman Home Plan 75174 which offers a comfortable and inviting living space with 3 bedrooms and 2 bathrooms. With 1,657 square feet of heated living area, a 267 square foot carport, and a combined front and rear porch space of 624 square feet, there's plenty of room to relax and enjoy the outdoors. Buyers are drawn to this new home plan because of its modern take on traditional craftsman. For example, the home presents with moody and modern gray siding and lovely tapered wooden columns with stone bases.

Updated Craftsman Home Plan With Covered Porches

Let's take a gander at the charming features. Firstly, as you enter Updated Craftsman Home Plan 75174 through the front porch, two doors open into the family room, where a vaulted ceiling and a cozy fireplace create a welcoming atmosphere. The living room measures 18'2 wide by 20' deep, and there is plenty of room to place comfortable seating around the fireplace. A third door leads to the dining room, providing seamless flow for entertaining and everyday living. Note that the dining room has an exit door leading out to the front covered porch. You may decide to head out there in the mornings to enjoy your coffee.

Secondly, the kitchen is a delightful space, featuring an island measuring 4' by 8' and complete with two sinks and casual seating. Don't worry about storage because there is a walk-in pantry which measures 5 feet wide by 6 feet deep. Furthermore, the corner pantry eliminates the need to create an awkward corner cabinet arrangement. Thirdly, you can access the back porch from the kitchen. As a result, this design enhances the indoor-outdoor connection, perfect for enjoying meals al fresco or simply savoring the fresh air.

3 Bedrooms On the Main Level

The master bedroom, located at the back of the house, boasts a 12' tray ceiling and offers direct access to the back porch. The ensuite bathroom is well-appointed with two vanities, a walk-in shower, a tub, and a private toilet. The master walk-in closet conveniently connects to the laundry area, ensuring functionality and efficiency. However, the connection is optional. If you do not connect the closet to the laundry, you will have more counter space and storage.

Two additional bedrooms are located at the front of the floor plan. They share a jack-n-jill bathroom which is really convenient for the kids. Close by, a staircase leads to 641 square feet of bonus expansion, offering endless possibilities for customization and additional living space to suit your needs and preferences.

What's Included?

Our working drawings include the following..
We use AutoCAD to produce our working drawings. This allows us to be 100% accurate on our dimensions as well as coordinate all drawings with the highest level of precision. Below are examples of what comes in each working drawing set...

Floor Plans - For each level we include... a 1/4"=1'-0" scale floor plan indicating frame walls and masonry with dimensions, notes, door and window sizes, room names and floor finishes, cabinet, shelving, fixture locations and notes, ceiling conditions, electrical/lighting fixtures and switches.

Exterior Elevations - We include... Front Elevation at 1/4"=1'-0", side and rear elevations at 1/8"=1'-0", plate heights, roof overhangs, material/surface notes, window heights, roof pitches, material hatching for clarity, floor to floor dimensions and any other detail we feel is necessary to explain the construction.

Cabinets/Building Sections- Cabinet elevations at 3/8"=1'-0", showing cabinets, appliance locations, plumbing fixtures, shelving, counter/backsplash surface, cabinet material and finish, niche details and any other special situation that cannot be understood from the plan view. Building Sections are included only when there is no other way to indicate the spatial characteristics of the home. This information is quite often indicated well enough on the elevations and plans.

Foundation Plans - We offer a choice of three types of foundations, full basement, crawlspace, and slab foundations. Each comes fully dimensioned, and noted indicating wall composition and thickness, construction detail references to our detail page, beam, pier and column locations and sizes, stair locations for basements, reinforcing steel sizes and step downs in monolithic slabs and ventilation grilles for crawlspaces.

Framing Plans - For each level we include... a 1/8"=1'-0" scale plan indicating rafter, ceiling and floor joists locations, sizes and spacing as well as lumber grade specified, additional bracing and blocking.

Details - For each foundation type we include... 3/4"=1'-0" scale details indicating material composition, size and critical dimensions for construction of the primary foundation.

Modifications

Want to make changes to a house plan at Family Home Plans?

Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. You will receive a FREE, no obligation, modification estimate to get exactly the home plan you've been dreaming of. Simply contact the modification department 1 of 3 ways:

Call 866-465-5866 and talk to a live person that can give you and FREE modification estimate over the phone!

Email Us - Please Include your telephone number, plan number, foundation type, state you are building in and a specific list of changes.

Fax: 651-602-5050 - Make sure to include a cover sheet with your contact info. Make attention to the FamilyHomePlans.com Modification Department.

Cost To Build

No Risk Offer: Order your Home-Cost Estimate now for just $24.95! We provide you with a 10% discount code in your receipt for when you decide to order any plan on our website that will more than pay you back!
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
Your estimate is active for 1 FULL YEAR!

View Sample

demo purposes only

Purchase

$24.95 per plan

** Available for U.S. only.

QUICK Cost-To-Build estimates have the following assumptions:

QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
** Available for U.S. only.

Q & A

Previous Q & A

Q: What type of wood are the posts made of

A: They could be made of anything but that golden brown look is going to be more natural with cedar.

Q: Is it a full wall behind the stove and cabinets ? Has upper cabinets there?

A: The uppers are hanging from the ceiling.

Q: Is the knee wall in the bonus room about four feet?

A: It’s 5’ at the very back wall. 3’ in front of the Mech/Stor.

Q: Is the 2x6 plan on 16" or 24" centers?

A: 16” oc

Q: Do you have any interior views, especially in reference to the range and hood area?

A: I'm sorry, I don't.

Q: Is there atic access?

A: Most of the useable attic is already included in the bonus areas but you could also add some access panels/doors to reach the rest of it.

Q: Questions on Plan # 75174 - Does the alcove have any windows? Do you have any interior photos? Thanks, I appreciate you!

A: There should be a double fixed window (2@30”x30”) shown on the artwork in the upper right corner of that space as shown in this drawing.

View Attached File

Q: What type of roof is recommended for this plan. We know tin is what it looks color and type is what we are looking for

A: This look is just a galvanized metal.

Q: What are the dimensions of the house with the 3 car garage?

A: Minimum foot print would be 80’-10” wide x 81’-5” deep

Q: Thank you for the pictures of the 3 car garage option. How and where is this attached to the house? Any pictures showing this?

A: It’s an owner decision. We do not specify.

Q: I am trying to do some planning for a mechanical room and was hoping to see a layout of the basement level. I wanted to do a sketchup model for my lot. If a rough one is available, would it be possible to get a rendering?

A: Unfortunately we do not do custom renderings but see attached.

View Attached File

Q: Do you have a basement floor plan for this plan?

A: Yes, its not complete. Need 24 hours notice.

Q: Does the slab show reinforced beams? What comes with the slab drawing?

A: Our slab foundation shows #3 rebar in the slab @ 12” oc each way. Beams have 2#5’s top and bottom. With #3 stirrups.

Common Q & A

Q: Can I make modifications to this plan?

A: Yes you can! Please click the "Modifications" tab above to get more information.

Q: What is the estimated price to build this plan?

A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.

FHP Low Price Guarantee

If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
