Garage-Living Plan 80902

• PDF File: $1,113.00
• 5 Sets: $1,344.00
• 5 Sets plus PDF File: $1,393.00
• CAD File: $1,533.00
  Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Materials List: $250.00
• Right Reading Reverse: $150.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $49.00

Materials List may take 3-5 weeks to fulfill depending on availability.

Available Foundation Types:

• Slab : No Additional Fee

Available Exterior Wall Types:

• 2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	632 sq ft
Main Living Area:	112 sq ft
Upper Living Area:	520 sq ft
Garage Area:	408 sq ft
Garage Type:	Attached
Garage Bays:	1
Foundation Types:	Slab
Exterior Walls:	2x6
House Width:	18'3
House Depth:	34'6
Number of Stories:	2
Bedrooms:	1
Full Baths:	1
Half Baths:	1
Max Ridge Height:	23'1 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Framing:	Stick
Deck:	110 sq ft
Main Ceiling Height:	8'
Upper Ceiling Height:	9'

Special Features:

• 2nd Floor Balcony
• Entertaining Space
• Open Floor Plan
• Storage Space

Plans include

a: Floor Plans: House plan drawings indicating dimensions for construction
b: Roof Plan: Drawings indicating roof slopes and unique conditions
c: Exterior Elevations: Drawings showing appearance and the types of materials used for the exterior finish
d: Building Sections: Drawings cut through important locations in the structure
e: Construction Details: Drawings showing specific construction of building elements at a large scale
f: Kitchen and bath elevations
g: Electrical Plans: Basic electrical layout (suggested locations of fixtures, switches and outlets)
h: Foundation Plan: Dimensioned drawings describing specific foundation conditions for the structure CRAWLSPACE

Plans are sent in AutoCAD 2000 format
