PDF Study Set: $2,000.00
Get your plans fast! A PDF Study Set is a complete set of plans stamped NOT FOR CONSTRUCTION. Not considered a license-to-build. Great for bidding purposes. Customer can upgrade within 90 days.
CAD File: $5,095.00 Single Build License issued on CAD File orders.
Available Foundation Types:
Basement
: $245.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Crawlspace
: $245.00
May require additional drawing time, please call to confirm before ordering.
Slab
: No Additional Fee
Walkout Basement
: $490.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Basement - * $245.00 Total Living Area may increase with Basement Foundation option. Crawlspace - * $245.00 Slab Walkout Basement - * $490.00 Total Living Area may increase with Basement Foundation option.
Exterior Walls:
2x6
House Width:
136'0
House Depth:
53'0
Number of Stories:
2
Bedrooms:
4
Full Baths:
3
Half Baths:
1
Max Ridge Height:
29'9 from Front Door Floor Level
Primary Roof Pitch:
0
Roof Framing:
Unknown
Main Ceiling Height:
10'
Upper Ceiling Height:
10'
* May require additional drawing time.
Special Features:
2nd Floor Balcony
Coat Closet
Dropzone
Entertaining Space
Open Floor Plan
Pantry
Storage Space
Two Master Bedroom
Plan Description
This unforgettable 2-story quadplex utilizes steel columns, numerous windows and exquisite masonry finishes in creating its unique visual appeal. The second-floor balcony, statement entry door, and contemporary lighting fixtures are perfect compliments. That balcony serves as a carport, while the garage’s extra depth offers storage. First- and second-floor suites make this an ideal layout for multi-generational households, particularly with the large upstairs loft for reading, play or study.
What's Included?
Cover Page
Each home plan features the rendered elevation and informative reference sections
including: general notes and design criteria; abbreviations; and symbols for your plan.
Foundation
Drafted at 1/4" scale. Poured or block basement or slab foundations are standard. We also show the structural information, steel beam and pole locations and the direction and spacing of
the floor system above. Optional basement, slab and crawl space foundations are available.
Main Level Floor Plan
1/4" scale. Fully dimensioned from stud to stud for ease of framing. 2"x4" walls are standard. The detailed
drawings include such things as structural header locations, framing layout and kitchen layout
Second Level Floor Plan.
1/4" scale. Dimensioned from stud to stud and drafted to the same degree of detail as the main level floor
plan.
Electrical and Sections
Illustrated on a separate page for clarity, the electrical plan shows suggested electrical layout for the
foundation, main and second level floor plans. Typical wall, cantilever, stair, brick and fireplace sections
are provided to further explain construction of these areas.
Roof Framing Plan.
Illustrated on a separate page for clarity, the roof framing plan shows the suggested dimensional plan
showing lengths, runs, ridge heights and wall plate heights.
Modifications
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
2. Print, complete and fax this PDF Form to us at 1-800-675-4916.
3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.
Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.
We Work Fast!
When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!
We look forward to hearing from you!
Start today planning for tomorrow!
Cost To Build
We are sorry, but an estimated cost build report is not available for this particular plan.
Q & A
Common Q & A
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
FHP Low Price Guarantee
If you find the exact same plan featured on a competitor's web site at a lower price, advertised OR special SALE price, we will beat the competitor's price by 5% of the total, not just 5% of the difference! Our guarantee extends up to 4 weeks after your purchase, so you know you can buy now with confidence.
Have any Questions? Please Call 800-482-0464 and our Sales Staff will be able to answer most questions and take your order over the phone. If you prefer to order online click the button below.
