Garage-Living Plan 83339
Contemporary , Modern Garage-Living Plan 83339 with 1040 Sq Ft, 2 Car Garage
sq ft
1040beds
0baths
0.5bays
2width
78'depth
70'
Click Any Image For Gallery
Plan Pricing from $1,100.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Additional Notes
Garage Height: 15'1"Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1040 sq ft |
| Main Living Area: | 1040 sq ft |
| Garage Area: | 2800 sq ft |
| Garage Type: | Detached |
| Garage Bays: | 2 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x6 |
| House Width: | 78'0 |
| House Depth: | 70'0 |
| Number of Stories: | 1 |
| Half Baths: | 1 |
| Max Ridge Height: | 23'9 from Front Door Floor Level |
| Primary Roof Pitch: | 4:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss |
| Main Ceiling Height: | 12' |
Plan Description
Modern Style, , 2 Car
Contemporary, Modern Style Garage-Living Plan 83339 with 1040 Sq Ft, 2 Car GarageSpecial Features:
