5 Car Garage Plan 83567
Garage - Storage Space for Vehicles of All Types | Plan 83567
Plan Pricing from $927.00
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Garage Area: | 1520 sq ft |
| Garage Type: | Detached |
| Garage Bays: | 5 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x6 |
| House Width: | 38'0 |
| House Depth: | 40'0 |
| Number of Stories: | 1 |
| Max Ridge Height: | 25'4 from Front Door Floor Level |
| Primary Roof Pitch: | 6:12 |
| Roof Load: | 25 psf |
| Roof Framing: | Truss |
| Main Ceiling Height: | 15'6 |
