3 Car Garage Apartment Plan 93472
Traditional Style 3 Car Garage Apartment with 1 Bed, 1 Bath
click for more images
Plan Pricing from $945.00
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 750 sq ft |
| Upper Living Area: | 750 sq ft |
| Garage Area: | 858 sq ft |
| Garage Type: | Detached |
| Garage Bays: | 3 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x4 2x6 - * $368.75 |
| House Width: | 38' |
| House Depth: | 24' |
| Number of Stories: | 2 |
| Bedrooms: | 1 |
| Full Baths: | 1 |
| Max Ridge Height: | 24'8 from Front Door Floor Level |
| Primary Roof Pitch: | 12:12 |
| Roof Framing: | Stick |
| Main Ceiling Height: | 8' |
| Upper Ceiling Height: | 9' |
Plan Description
The Hudson Carriage House is a 3 car garage with a 750 sq. ft. studio above. With siding exterior reminiscent of a country barn, this plan would be perfect temporary quarters during construction of your permanent home. Or it would be ideal for an in-law apartment, nanny quarters, college student apartment, etc. This design features an eat-in kitchen, a spacious family room, a bathroom and a bedroom with a roomy closet The laundry appliances are tucked beneath the stairs on the garage level with an optional laundry chute on the living level.
