3 Car Garage Apartment Plan 93485
Craftsman Style 3 Car Garage Apartment with 1 Bed, 3 Bath, RV Storage | Plan 93485
Plan Pricing from $1,045.00
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1548 sq ft |
| Lower Living Area: | 490 sq ft |
| Main Living Area: | 1058 sq ft |
| Garage Type: | Drive Under |
| Garage Bays: | 3 |
| Foundation Types: | Slab |
| Exterior Walls: | 2x6 |
| House Width: | 57'6 |
| House Depth: | 45'0 |
| Number of Stories: | 1 |
| Bedrooms: | 1 |
| Full Baths: | 2 |
| Half Baths: | 1 |
| Max Ridge Height: | 24'3 from Front Door Floor Level |
| Primary Roof Pitch: | 12:12 |
| Roof Framing: | Stick |
| Porch: | 160 sq ft |
| FirePlace: | Yes |
Special Features:
Plan Description
This functional design offers much more than just garage space! The versatile arrangement has parking for 2 vehicles, 1 small RV such as a 4-wheeler, etc. and a larger garage for a boat or a luxury RV. The small RV storage area could also serve as a bunk room since it features a mini kitchen and a bathroom with a shower. Located behind the larger RV storage garage is an eat-in kitchen and another full bath with a shower. A spiral staircase leads up to a private bunk room. The main garage has 9 ft ceilings and accesses a laundry closet, a covered porch and an RV cleanup pad. The upper level is accessed from the bunk room. Upstairs is a home away from home! The spacious family room features a fireplace and a vaulted ceiling with a ceiling fan and has doors leading to a screened porch. Adjoining the family room is an eat-in kitchen with a snack bar. This level is completed by a bedroom which features a separate entry to the main bathroom and a walk-in closet.
