House Plan 24302

• PDF Study Set: $600.00
  Get your plans fast! A PDF Study Set is a complete set of plans stamped NOT FOR CONSTRUCTION. Not considered a license-to-build. Great for bidding purposes. Customer can upgrade within 90 days.
• PDF File: $800.00
• 1 Set: $600.00
• 5 Sets: $700.00
• 5 Sets plus PDF File: $900.00
• Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Materials List: $150.00
• Right Reading Reverse: $100.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
• Additional Sets: $50.00

Additional Notes

Related Plan: 24303

Plans are not to be sold in New Jersey or Maryland.

Available Foundation Types:

• Basement : No Additional Fee
  Total Living Area may increase with Basement Foundation option.
• Crawlspace : No Additional Fee

Available Exterior Wall Types:

• 2x4: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	988 sq ft
Main Living Area:	988 sq ft
Unfinished Basement Area:	988 sq ft
Garage Area:	280 sq ft
Garage Type:	Attached
Garage Bays:	1
Foundation Types:	Basement Crawlspace
Exterior Walls:	2x4
House Width:	54'
House Depth:	28'
Number of Stories:	1
Bedrooms:	3
Full Baths:	1
3/4 Baths:	1
Max Ridge Height:	18' from Front Door Floor Level
Primary Roof Pitch:	8:12
Roof Load:	45 psf
Roof Framing:	Stick
Porch:	127 sq ft
1st Floor Master:	Yes
Main Ceiling Height:	8'

* May require additional drawing time.

A Call to Comfort

While it’s all about using space creatively, there’s no lack of pretty detailing here. A bright Palladian window and double peaked roofs caress the exterior while space-saving artfulness tweaks the 988 sq. ft. interior. The airy atmosphere is achieved by opening the living room to the dining room and by the dining room flowing easily into the kitchen and beyond to a covered patio. Two cozy bed rooms at the front of the house share a bathroom. The master bedroom tucks cozily at the rear of the house and enjoys its own bathroom. Closets are arranged to give maximum storage. The garage, too, offers an option for expansion
