House Plan 55859
One-Story Style, 1619 Sq Ft, 3 Bed, 2 Bath, 2 Car | Plan 55859
sq ft
1619beds
3baths
2bays
2width
42'depth
41'
Click Any Image For Gallery
Plan Pricing from $1,150.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Additional Notes
Total - Under Roof 2,078 Sq.Ft.Floor: Live Load 40
Floor: Dead Load 25
Roof: Live Load 30
Roof: Dead Load 25
Wind Speed 140
Roof Material C.Tile
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1619 sq ft |
| Main Living Area: | 1619 sq ft |
| Garage Area: | 403 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Slab |
| Exterior Walls: | Concrete |
| House Width: | 42' |
| House Depth: | 40'8 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Max Ridge Height: | 17'9 from Front Door Floor Level |
| Primary Roof Pitch: | 5:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss |
| Porch: | 70 sq ft |
| 1st Floor Master: | Yes |
