Plan Pricing from $1,940.00

Plan Pricing

PDF File: $1,940.00
CAD File: $2,190.00
Single Build License issued on CAD File orders.

Need A Materials List?

It seems that this plan does not offer a stock materials list, but we can make one for you. Please call 1-800-482-0464, x403 to discuss further.

Right Reading Reverse: $75.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

Need Printed Sets?

It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.

Available Foundation Types:

Plumbing Plan : No Additional Fee

Available Exterior Wall Types:

Unknown: No Additional Fee

Prices subject to approval prior to fulfillment.

Shipping Policy

Add to cart

Specifications

Total Living Area:	2793 sq ft
Main Living Area:	2793 sq ft
Garage Area:	491 sq ft
Garage Type:	Attached
Garage Bays:	3
Foundation Types:	Plumbing Plan
Exterior Walls:	Unknown
House Width:	68
House Depth:	88
Number of Stories:	1
Bedrooms:	3
Full Baths:	4
Max Ridge Height:	24 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Framing:	Unknown
Porch:	196 sq ft
1st Floor Master:	Yes

Plan Description

Classic Mediterranean styling lends a relaxed demeanor to this sophisticated design. On the inside, the foyer blends seamlessly with the both the dining room and living room – and the eye is immediately drawn to views beyond the covered lanai. An appropriately named Leisure Room rests at the rear of the home and is open to the kitchen and breakfast area. Secondary bedrooms lie nearby, each with easy access to a bath. The master suite resides on the opposite side of the floor plan and enjoys direct access to the lanai.

What's Included?

1. Cover Page (A-1) - Front Elevation of House, Sheet Index, General Notes

2. Plumbing Plan (A-2) - (**Our plans do not show an actual foundation plan with slab thickness and structural reinforcement due to the fact that the plans need to be engineered according to the local codes where the house is going to be built.) Basic slab or stemwall foundation layout, Exterior dimensions, Dimensions to plumbing fixtures, General Notes

3. Note Plan (A-3) - Floor plan, General notes, Basic window and door schedules

4. Dimension Plan (A-4) - Interior dimensions of plan, Exterior dimensions of plan

5. Elevations (A-5) - 4 Elevations of house (Front, Rear, Left and Right), General call outs, Roof pitch, Truss bearing heights, General notes, Details (where applicable)

6. Roof Plan (A-6) - Floor plans with a general roof design layout, Overhang dimensions, Truss bearing heights, beam slopes, and beam height changes, General notes

7. Sections Page (A-7) - General wall sections, Misc. details (stairs, tie beam, window and door buck details)

8. Electrical Plan (E-1) - General layout of switches, outlets and wiring, General television, and phone jack locations, General notes
