Plan Pricing from $370.00

Plan Pricing

PDF File: $370.00
CAD File: $670.00
Single Build License issued on CAD File orders.
Right Reading Reverse: $100.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Additional Sets: $50.00

Need Prints?

It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.

Additional Notes

Foundation plan is a floating slab
65303,64835,64837 are this garage plan in different sizes

** Please note that a PDF File is included with a 3 Set Order**

**All plans by this designer are being updated to IRC 2015 starting on March 13, 2023. This plan may be delayed by 4 business days before shipping.**

Available Foundation Types:

Slab : No Additional Fee

Available Exterior Wall Types:

2x6: No Additional Fee

Prices subject to approval prior to fulfillment.

Shipping Policy

Add to cart

Specifications

Bonus Area:	281 sq ft
Garage Area:	468 sq ft
Garage Type:	Detached
Garage Bays:	1
Foundation Types:	Slab
Exterior Walls:	2x6
House Width:	18'
House Depth:	26'
Number of Stories:	2
Max Ridge Height:	21'11 from Front Door Floor Level
Primary Roof Pitch:	0
Roof Framing:	Unknown

What's Included?

All our house plans include:

-4 elevations
-Foundation plan
-Ground floor plan
-Upper floor plan (if applicable)
-Roof plan
-Truss diagrams and building sections (manufactured trusses required – no structural details included)
-Construction details
-Typical wall section

NOT included:

-Engineering
-HVAC (Heating, ventilation and air conditioning)
-Electrical and plumbing plans

What's included in our house plans detail

BCIN # for Ontario customers is available at an additional charge

-House plans with or without garage and / or apartment $300
-Multi-unit plans $400
-All other plans $150
-Garage plans with NO heating elements, $200 charge for BCIN
If you are purchasing a BCIN number for Ontario customers, and wish to purchase the PDF, a copy per Ontario rules must be mailed as well. There is no charge for the actual copy, but shipping on the copy must be purchased.

Modifications

Want to make changes to a house plan at Family Home Plans?

Plan modification is a way of turning a stock plan into your unique custom plan. It's still just a small fraction of the price you would pay to create a home plan from scratch. You will receive a FREE, no obligation, modification estimate to get exactly the home plan you've been dreaming of. Simply contact the modification department 1 of 3 ways:

Call 866-465-5866 and talk to a live person that can give you and FREE modification estimate over the phone!

Email Us - Please Include your telephone number, plan number, foundation type, state you are building in and a specific list of changes.

Fax: 651-602-5050 - Make sure to include a cover sheet with your contact info. Make attention to the FamilyHomePlans.com Modification Department.

Q & A

Ask the Designer any question you may have. NOTE: If you have a plan modification question, please click on the Plan Modifications tab above.

Previous Q & A

Q: Does the slab have details on construction of it and does it meet Canadian standards?nic_

A: Good day and thank you for your intererst in our plans

Our plans meet or exceed most Canadian standards and we can supply the BCIN for Ontario residents if required.

The foundation plan for the slab includes the pertinent details on construction.

Please let me know if you have any other questions or comments

Regards

Deborah

Q: Re: Garage Plan 64836 What is the roof pitch on this design? Also What is the floor to peak measurement in the bonus room, then the measurement at 6' from center. Thank You, Mike.

A: The roof pitch for this plan is 14/12. The peak in the bonus area is at 7'-0" and the knee wall is at 3'-9".

Q: Can you tell me 1st flr ceiling ht, wall ht to top plate, 2nd flr to bottom of ridge beam and/or collar beam. Want unit like 64836. Can live with 7.5 ft fst flr clearance if increased head room on 2nd. Also, can go 28 ft depth. Have not decided on exterior siding/veneer/stucco, etc. Before I order, would like to see framing cross section. I would prefer conventional framing over trusses but can live with trusses if they do not clutter my loft area. Am located in Phoenix. Look forward to your response - Thanks, Russ

A: The first floor ceiling height is 8'-6" from slab to ceiling, the wall height to top plate is 8'-2". Second floor is 7'-0". You can have the plan modified to get 28 feet depth. The roof system is made of trusses with the floor incorporated in it.

Q: What is the height of the kneewalls in the loft area?

A: The height of the knee wall is 3'-9".

Common Q & A

Q: Can I make modifications to this plan?

A: Yes you can! Please click the "Modifications" tab above to get more information.

Q: What is the estimated price to build this plan?

A: The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
