Master Bedroom Dbl Coffer 12' - 14'
Master Bath Vaulted
Living Room Coffer w/beams 14'6" - 17'
Family Room Coffer w/beams 12' - 13'4"
Dining Room Coffer w/beams 12' - 13'
Kitchen Tray w/beams 14' - 16'
Dinette Coffer w/beams 12' - 13'8"
Entry Flat 16'
Foyer Dbl Coffer 14'6" - 17'
Study Dbl Coffer 12' - 14'
Bedroom 2 Coffered 12' - 13'
Bedroom 3 Coffered 10' - 11'
Bedroom 4 Coffered 10' - 11'
Baths Flat 10'
Bath #2 Flat 12'
Powder Bath Flat 12'
Pool Bath Flat 10'
Lanai Level One Coffer w/beams 12' - 15'4"

THIS PLAN CANNOT BE SOLD FOR CONSTRUCTION ANYWHERE IN THE STATE OF FLORIDA WITHOUT DESIGNER APPROVAL. Please call for availability.

Available Foundation Types:

Slab : No Additional Fee

Available Exterior Wall Types:

2x6: $350.00
(Please call for drawing time.)
Concrete: No Additional Fee

Prices subject to approval prior to fulfillment.

Shipping Policy

Add to cart

Specifications

Total Living Area:	4828 sq ft
Main Living Area:	4828 sq ft
Garage Area:	1015 sq ft
Garage Type:	Attached
Garage Bays:	3
Foundation Types:	Slab
Exterior Walls:	2x6 - * $350.00 Concrete
House Width:	89'6
House Depth:	136'4
Number of Stories:	1
Bedrooms:	4
Full Baths:	4
Half Baths:	2
Max Ridge Height:	29'4 from Front Door Floor Level
Primary Roof Pitch:	6:12
Roof Framing:	Truss
Porch:	1665 sq ft
Formal Dining Room:	Yes
FirePlace:	Yes

* May require additional drawing time.

Special Features:

Outdoor Pool
