House Plan 78506

Mediterranean Style with 5 Bed, 5 Bath, 4 Car Garage | Plan 78506

sq ft

5183

beds

baths

4.5

bays

width

78'

depth

69'

Turn OFF Image Gallery

Add to cart

Plan Pricing from $2,574.00

Plan Pricing

PDF Study Set: $2,398.00
Get your plans fast! A PDF Study Set is a complete set of plans stamped NOT FOR CONSTRUCTION. Not considered a license-to-build. Great for bidding purposes. Customer can upgrade within 90 days.
PDF File: $2,574.00
5 Sets: $2,354.00
8 Sets: $2,442.00
Reproducible Set: $2,750.00
CAD File: $2,882.00
Single Build License issued on CAD File orders.
Materials List: $588.50
Right Reading Reverse: $200.00
All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.
Additional Sets: $40.00

Additional Notes

Coffered Ceiling in Family Room Coffered Ceiling in Formal Dining Room Walk in Pantry 2 Offices 2 Game Rooms Gym Kitchenette in Basement Separate His and Her Closets Jack & Jill Bathroom 5 Car Garage

Available Foundation Types:

Walkout Basement : No Additional Fee
Total Living Area may increase with Basement Foundation option.

Available Exterior Wall Types:

2x4: No Additional Fee

Prices subject to approval prior to fulfillment.

Shipping Policy

Add to cart

Specifications

Total Living Area:	5183 sq ft
Lower Living Area:	1547 sq ft
Main Living Area:	2504 sq ft
Upper Living Area:	1132 sq ft
Garage Area:	681 sq ft
Garage Type:	Attached
Garage Bays:	4
Foundation Types:	Walkout Basement
Exterior Walls:	2x4
House Width:	77'6
House Depth:	68'4
Number of Stories:	3
Bedrooms:	5
Full Baths:	4
Half Baths:	1
Max Ridge Height:	30'10 from Front Door Floor Level
Primary Roof Pitch:	10:12
Roof Load:	15 psf
Roof Framing:	Unknown
Porch:	810 sq ft
Formal Dining Room:	Yes
FirePlace:	Yes
1st Floor Master:	Yes
Main Ceiling Height:	10'

* May require additional drawing time.

Special Features:

Deck or Patio
Dropzone
Exercise Room
Hobby Room
Jack and Jill Bathroom
Mudroom
Office
Outdoor Fireplace
Pantry
Rear Porch
Storage Space
