Misc Plan 81659

• PDF File: $650.00
• CAD File: $1,050.00
  Single Build License issued on CAD File orders.
• Concerning PDF or CAD File Orders: Designer requires that a End User License Agreement be signed before fulfilling PDF and CAD File order.
• Right Reading Reverse: $250.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

$95.00 to add a PDF File to a CAD file order. Call the sales office to add this option to your order.

Available Foundation Types:

• Slab : No Additional Fee

Available Exterior Wall Types:

• 2x4: No Additional Fee
• 2x6: $350.00
  (Please call for drawing time.)

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	87 sq ft
Main Living Area:	87 sq ft
Bonus Area:	293 sq ft
Garage Type:	None
Foundation Types:	Slab
Exterior Walls:	2x4 2x6 - * $350.00
House Width:	20'0
House Depth:	22'0
Number of Stories:	1
Half Baths:	1
Max Ridge Height:	16'2.5 from Front Door Floor Level
Primary Roof Pitch:	0
Roof Framing:	Unknown
Main Ceiling Height:	10'1

* May require additional drawing time.

Special Features:

• Outdoor Fireplace

Poolside Pavilion with Outdoor Kitchen, Outdoor Fireplace and Bathroom. Cabana Ideas and Plans

This Pool House Plan has a small footprint of 20' W by 22' D, and 87 square feet living space. For those who need function and a little luxury, this tidy pool house has a bathroom with shower and even a closet to store a few things like sunscreen and bug spray. When it comes to pool rafts, volleyball nets, and air pumps, the storage room has you covered. Then, we move on to the luxury: this pool house design includes a full outdoor kitchen for grilling hamburgers, plus a cozy outside fireplace!
