House Plan 55889
One-Story Style House Plan 55889 with 3415 Sq Ft, 3 Bed, 5 Bath, 3 Car Garage
sq ft
3415beds
3baths
3.5bays
3width
93'depth
69'Click Any Image For Gallery
Plan Pricing from $1,350.00
Plan Pricing
Need Printed Sets?
It seems that this plan only offers electronic (PDF or CAD) files. If you also need Printed Sets, please call 1-800-482-0464, x403 to discuss possible options.Additional Notes
Total - Under Roof 4,786 Sq.Ft.Floor: Live Load 40
Floor: Dead Load 25
Roof: Live Load 30
Roof: Dead Load 25
Wind Speed 140
Roof Material C. Tile
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 3415 sq ft |
| Main Living Area: | 3415 sq ft |
| Garage Area: | 840 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 3 |
| Foundation Types: | Slab |
| Exterior Walls: | Concrete |
| House Width: | 93' |
| House Depth: | 68'10 |
| Number of Stories: | 1 |
| Bedrooms: | 3 |
| Full Baths: | 3 |
| 3/4 Baths: | 1 |
| Half Baths: | 1 |
| Max Ridge Height: | 21'9 from Front Door Floor Level |
| Primary Roof Pitch: | 5:12 |
| Roof Load: | 40 psf |
| Roof Framing: | Truss |
| Porch: | 497 sq ft |
| Deck: | 388 sq ft |
| Formal Dining Room: | Yes |
| 1st Floor Master: | Yes |
| Main Ceiling Height: | 9' |
