Basement
: $466.00
May require additional drawing time, please call to confirm before ordering.
Total Living Area may increase with Basement Foundation option.
Basement - * $466.00 Total Living Area may increase with Basement Foundation option. Crawlspace Slab
Exterior Walls:
2x6
House Width:
28'0
House Depth:
42'0
Number of Stories:
2
Bedrooms:
3
Full Baths:
2
Half Baths:
1
Max Ridge Height:
28'7 from Front Door Floor Level
Primary Roof Pitch:
9:12
Roof Load:
25 psf
Roof Framing:
Truss
FirePlace:
Yes
Main Ceiling Height:
9'0
* May require additional drawing time.
Special Features:
Brick or Stone Veneer
Front Porch
Narrow Lot
Office
Open Floor Plan
Pantry
Storage Space
Plan Description
3 Bedroom Cottage House Plan
On the outside, this home is one of those picturesque little cottages that inspires artists to create dreamy paintings of quiet homesteads. Between the classic look of the front porch and the quaint gables, this home begs to be surrounded with country gardens that are always in bloom. Add an orchard to your landscape and you will enjoy a comfortable, beautiful lifestyle that most people can only dream about.
After a long day of enjoying your gardens, where will you spend the evening? Perhaps it will be in the kitchen, preparing the foods that you spent the day harvesting. With the wraparound counter and large central island, you will have ample room to preserve homemade vegetables or make decadent desserts with the fruits from your orchard.
Perhaps you would simply like to relax after a long, hard day. If so, then kick back in the vaulted living room. Enjoy the view through this rooms many windows, indulge in your favorite TV shows or read a book next to the crackling fire.
If you are an entrepreneur, you will put the office to good use. With the picture window, you will be able to enjoy the sunshine as you work. Built-in shelving lets you stay organized and there is ample floor space for a large desk and office equipment. Plus, the secluded location gives you a peaceful, distraction-free zone so that you can work at maximum efficiency.
If you enjoy DIY projects, the one-car garage might just become your favorite place to hang out. Park to the front of the garage and fill the rear space with the work benches, tools and storage solutions that you need to complete your projects.
Imagine all the sleepovers your children will host in the upper floor. Built-in closets give each of your kids a place to store clothes, toys and more. With a large floor plan, they will have plenty of space to spread out and play games with their friends.
The upper floor also plays host to the master suite, a well-designed space that gives you a private bathroom, walk-in closet with shelving and more. Here, you will enjoy the fresh feeling that comes from a large picture window and vaulted ceilings. Before you go to bed each night, you will take a moment to look out through the picture window and enjoy the beautiful landscape that you worked so hard to create.
What's Included?
Exterior Elevations
In addition to the front exterior, your drawing set will include drawings of the rear and sides of your house as well. These drawings give notes on exterior materials and finishes. Particular attention is given to cornice detail, brick and stone accents, or other finish items that make your home unique.
Note: Sections and Elevations depict the default foundation, regardless of optional foundation page choices
Foundation Plan
The foundation page dimensions, concrete walls, footings, pads, posts, beams, bearing walls, and any stepped foundation information along with any retaining wall info (schematic only). A typical wall section for the home is also usually included on this page (if not, it is elsewhere in your plan set, as space allows). If your plan features a poured concrete slab rather than a basement or crawlspace, the foundation page shows footings and details for the slab, and includes plumbing locations.
Floor Plan(s)
Exterior and interior wall framing, and windows/doors are dimensioned. Room sizes are indicated and any beams, posts and structural bearing points are called out. The floorplans include an electrical legend, and electrical fittings, lights and outlets are shown. Floor Plans will also indicate cross–section details (provided on the sections page) and show any special framing details applicable to the design. Cabinet elevations are included for kitchen and bathrooms; some designs feature cabinet elevations for design–related built–ins too.
Building Sections
Building sections show changes in floor, ceiling, or roof height, and the relationship of one level to another. Our section pages also show how the stairs are calculated (if there are some) and depict roof and foundation members. We try and draw sections to show the most useful information — choosing locations where there are elements you or your contractor might need clarification on.
Note: Sections and Elevations depict the default foundation, regardless of optional foundation page choices
Roof Plan
Roof framing or truss directions are shown, slope directions are indicated and structural members are sized and called out if applicable. The gravity loads used to calculate the rafters, beams and posts are indicated , and we also show gutters, downspouts, and any roof venting required for your home.
Notes and Details Page(s)
Your home comes detailed to meet the requirements of the latest adopted version of the ‘International Residential Code’, and our notes and details pages outline all the elements applicable to the design of your home. Compliance with further standards may need to be incorporated into your plan set, depending on the requirements of your building department — these are usually done locally.
Modifications
Receive a FREE modification estimate in one of 3 ways. Our modification team is ready to help you adjust any plan to fit your needs. The ReDesign process is simple and estimates are free!
2. Print, complete and fax this PDF Form to us at 1-800-675-4916.
3. Want to talk to an expert? Call us at 913-938-8097 (Canadian customers, please call 800-361-7526) to discuss modifications.
Note: - a sketch of the changes or the website floor plan marked up to reflect changes is a great way to convey the modifications in addition to a written list.
We Work Fast!
When you submit your ReDesign request, a designer will contact you within 24 business hours with a quote.
You can have your plan redesigned in as little as 14 - 21 days!
We look forward to hearing from you!
Start today planning for tomorrow!
Cost To Build
No Risk Offer: Order your Home-Cost Estimate now for just $24.95! We provide you with a 10% discount code in your receipt for when you decide to order any plan on our website that will more than pay you back!
Get more accurate results, quicker! No need to wait for a reliable cost.
Get a detailed cost report for your home plan with over 70 lines of summarized cost information in under 5 minutes!
Cost report for your zip code. (the zip code can be changed after you receive the online report)
Estimate 1, 1-1/2 or 2 story home plans. **
Interactive! Instantly see the costs change as you vary quality levels Economy, Standard, Premium and structure such as slab, basement and crawlspace.
QUICK Cost-To-Build estimates have the following assumptions:
QUICK Cost-To-Build estimates are available for single family, stick-built, detached, 1 story, 1.5 story and 2 story home plans with attached or detached garages, pitched roofs on flat to gently sloping sites.
QUICK Cost-To-Build estimates are not available for specialty plans and construction such as garage / apartment, townhouse, multi-family, hillside, flat roof, concrete walls, log cabin, home additions, and other designs inconsistent with the assumptions outlined in Item 1 above.
User is able to select and have costs instantly calculate for slab on grade, crawlspace or full basement options.
User is able to select and have costs instantly calculate different quality levels of construction including Economy, Standard, Premium. View Quality Level Assumptions.
Estimate will dynamically adjust costs based on the home plan's finished square feet, porch, garage and bathrooms.
Estimate will dynamically adjust costs based on unique zip code for project location.
All home plans are based on the following design assumptions: 8 foot basement ceiling height, 9 foot first floor ceiling height, 8 foot second floor ceiling height (if used), gable roof; 2 dormers, average roof pitch is 12:12, 1 to 2 covered porches, porch construction on foundations.
Summarized cost report will provide approximately 70 lines of cost detail within the following home construction categories: Site Work, Foundations, Basement (if used), Exterior Shell, Special Spaces (Kitchen, Bathrooms, etc), Interior Construction, Elevators, Plumbing, Heating / AC, Electrical Systems, Appliances, Contractor Markup.
QUICK Cost-To-Build generates estimates only. It is highly recommend that one employs a local builder in order to get a more accurate construction cost.
All costs are "installed costs" including material, labor and sales tax.
** Available for U.S. only.
Q & A
Common Q & A
Q:Can I make modifications to this plan?
A:Yes you can! Please click the "Modifications" tab above to get more information.
Q:What is the estimated price to build this plan?
A:The national average for a house is running right at $125.00 per SF. You can get more detailed information by clicking the Cost-To-Build tab above. Sorry, but we cannot give cost estimates for garage, multifamily or project plans.
