House Plan 52986

• PDF File: $1,565.00
• CAD File: $1,565.00
  Single Build License issued on CAD File orders.
• Right Reading Reverse: $250.00
  All sets will be Readable Reverse copies. Turn around time is usually 3 to 5 business days.

PLAN RESTRICTIONS: CANNOT BE SOLD TO BE BUILT IN LEE OR COLLIER COUNTIES, FLORIDA

Available Foundation Types:

• Slab : No Additional Fee

Available Exterior Wall Types:

• 2x4: $250.00
  (Please call for drawing time.)
• 2x6: $250.00
  (Please call for drawing time.)
• 2x8: $250.00
  (Please call for drawing time.)
• Concrete: No Additional Fee

Prices subject to approval prior to fulfillment.

• Shipping Policy

Total Living Area:	1738 sq ft
Main Living Area:	1738 sq ft
Garage Area:	688 sq ft
Garage Type:	Attached
Garage Bays:	2
Foundation Types:	Slab
Exterior Walls:	2x4 - * $250.00 2x6 - * $250.00 2x8 - * $250.00 Concrete
House Width:	58'2"
House Depth:	63'6"
Number of Stories:	1
Bedrooms:	2
Full Baths:	2
Max Ridge Height:	23'11" from Front Door Floor Level
Primary Roof Pitch:	5:12
Roof Framing:	Truss
Main Ceiling Height:	9'4"

* May require additional drawing time.
