House Plan 83565
Economic Footprint, Amenity Rich Livability | Plan 83565
sq ft
1677beds
3baths
2.5bays
2width
36'depth
52'
Plan Pricing from $1,460.00
Plan Pricing
Available Foundation Types:
Available Exterior Wall Types:
Prices subject to approval prior to fulfillment.Specifications
| Total Living Area: | 1677 sq ft |
| Main Living Area: | 836 sq ft |
| Upper Living Area: | 841 sq ft |
| Garage Area: | 481 sq ft |
| Garage Type: | Attached |
| Garage Bays: | 2 |
| Foundation Types: | Basement - * $484.00 Total Living Area may increase with Basement Foundation option. Crawlspace Slab |
| Exterior Walls: | 2x6 |
| House Width: | 36'0 |
| House Depth: | 52'0 |
| Number of Stories: | 2 |
| Bedrooms: | 3 |
| Full Baths: | 2 |
| Half Baths: | 1 |
| Max Ridge Height: | 28'2 from Front Door Floor Level |
| Primary Roof Pitch: | 9:12 |
| Roof Load: | 25 psf |
| Roof Framing: | Truss |
| Porch: | 317 sq ft |
| FirePlace: | Yes |
| 2nd Floor Laundry: | Yes |
| Main Ceiling Height: | 9' |
| Upper Ceiling Height: | 9' |
